![Omron NYB1E-C13C6 [248/276] Appendices](/views2/1872506/page248/bgf8.png)
Item Default / Remark
Platform Controller
Hub (PCH)
SATA And RST Con-
figuration
Hot Plug Disabled
Spin Up Device Disabled
SATA Device Type Hard Disk Drive
Topology Unknown
SATA Port 2 DevSlp Disabled
DITO Configuration Disabled
USB Configuration XHCI Disable Compliance Mode False
xDCI Support Disabled
USB Port Disable Override Disabled
TraceHub Configura-
tion menu
TraceHub Enable Mode Disable
MemRegion 0 Buffer Size 1MB
MemRegion 1 Buffer Size 1MB
DCI enable (HDCIEN) Disabled
PCH LAN Controller Enabled
DeepSx Power Policies Disabled
LAN Wake From DeepSx Enabled
Wake on LAN Enable Enabled
SLP_LAN# Low on DC Power Enabled
K1 off Enabled
Wake on WLAN and BT Enable Disabled
Disable DSX ACPRESENT Pulldown Disabled
Serial IRQ Mode Continuous
Port 61h Bit-4 Emulation Enabled
Port 80h Redirection LPC Bus
Enhance Port 80h LPC Decoding Disabled
Compatible Revision ID Disabled
PCH Cross Throttling Enabled
Disable Energy Reporting FALSE
Enable TCO Timer Disabled
Pcie P11 SSC Auto
IOAPIC 24-119 Entries Enabled
Unlock PCH P2SB Disabled
Flash Protection Range Registers (FPRR) Disabled
SPD Write Disable TRUE
ChipsetInit HECI Message Enabled
Bypass ChipsetInit sync reset Disabled
*1. Disabled when a storage device is not present on SATA port.
Appendices
A-48
NY-series Industrial Box PC Hardware User's Manual (W553)
