NYB27-£0 Temperature Specifications
Ambient operating temperature specifications for model NYB27-£0.
This Box PC has an Intel
®
Core
™
i7-7820EQ CPU.
Additional Information
Refer to 1-4 Product Configuration Box PC on page 1-5 for model details.
Mounting Orientation
Storage device type
*1
CFast Card
Book 0 to 55°C
Wall 0 to 55°C
*1. Refer to 1-4 Product Configuration Box PC on page 1-5 for model details.
NYB27-£1, NYB27-£2 T
emperature Specifications
Ambient operating temperature specifications for model NYB27-£1 and NYB27-£2.
This Box PC has an Intel
®
Core
™
i7-7820EQ CPU.
Additional Information
Refer to 1-4 Product Configuration Box PC on page 1-5 for model details.
Mounting Ori-
entation
Storage device type
*1
1 x SSD 2 x SSD
1 x HDD
*2
2 x HDD
*2
1 x SSD 1 x
HDD
*2
Book 0 to 55°C 5 to 45°C 5 to 35°C 5 to 45°C
Wall 0 to 55°C 5 to 45°C 5 to 35°C 5 to 45°C
*1. Refer to 1-4 Product Configuration Box PC on page 1-5 for model details.
*2. Ambient operating temperature specifications when using a 1 TB HDD:
Mounting Orientation
Storage device type
1 x HDD 2 x HDD 1 x SSD 1 x HDD
Book 0 to 40°C 5 to 30°C 0 to 35°C
Wall 0 to 40°C 5 to 30°C 0 to 35°C
4 Specifications
