Power Supply Design and Turning ON/OFF the Power Supply
• Always use a power supply that provides power within the rated range in the manual.
•
Do not perform a dielectric strength test.
• Always use the recommended uninterruptable power supply (UPS) to prevent data loss and other
system file integrity issues caused by unexpected power interruption. Back up the system files in the
planned way to prevent data loss and other system file integrity issues caused by incorrect opera-
tion.
•
Use an Omron S8BA UPS with the correct revision number to prevent improper system shutdown.
• Power ON after connecting the product and an external monitor.
• Always check the power supply and power connections before applying power. Incorrect power con-
nections can damage the product or cause burning.
• Always turn OFF the power supply to system before you attempt any of the following.
• Inserting or removing PCIe Cards
• Connecting cables
• Connecting or disconnecting the connectors
• Wiring the system
• Replacing or removing the storage device
• Replacing the Battery
• Replacing the Fan Unit
Actual Operation
• Choose a OS password that is not obvious to prevent unauthorized access.
•
Remember the OS user name and password. The product is inaccessible without it.
• Before operating the system , please make sure the appropriate software is installed and config-
ured. Doing so may prevent unexpected operation.
•
Install all updates and ensure the browser stays up-to-date.
• Install all updates and ensure the firewall stays up-to-date.
• Install all updates and ensure virus definitions stay up-to-date.
• Make sure that your OS environment is protected against malicious software and viruses.
• Do not remove the fan cover while the power is ON. Contact with a rotating fan may result in injury.
• Virtual memory settings can affect the performance of the system. Disable the paging file after in-
stallation of applications or updates.
• Correctly perform wiring and setting, and ensure that the shutdown by the UPS can be executed.
• Always use the SMART monitoring feature for storage devices that do not comply to the Omron
Storage Device Specifications. Monitor the operating temperature and vibrations to ensure they stay
within the environmental specifications of the storage device.
Operation
• Do not carry out the following operations when accessing a USB device or an SD Memory Card.
•
Turn OFF the power supply of the product.
•
Press the Power Button of the product.
• Remove a USB device or SD memory card.
• Do not attempt to remove or touch the fan unit while the product is powered ON or immediately after
the power supply is turned OFF. If you attempt to replace the fan unit then, there is a risk of personal
injury due to hot or rotating parts.
Precautions for Safe Use
19
NY-series Industrial Box PC Hardware User's Manual (W553)
