ROTARY LASER ROTARY LASER

10 11

user manual user manual

EN EN

CONDTROL Green RotoLaser CONDTROL Green RotoLaser

Laser receiver

Laser receiver allows using the product outdoor as well as while

intensive sunshine at distance up to 400 m (in diameter) when it’s

difficult to recognize laser beam.

1 2 3

OPERATION

Battery charging

In case power indicator starts flashing while operation – batteries

need to be charged. Please use battery charger included in the set.

Full charging takes approximately 5 hours. While charging red light

indicator on battery charger will be on. As soon as indicator becomes

1. Turn on/off

2. Turn on/off sound signal

3. High/normal accuracy mode

4. Display

5. Receiver sensor

green, batteries are fully charged, battery charger can be unplugged.

Take batteries out of the product if it is not used for a long time. All

batteries should be of the same type and brand with the same charge

level. Do not leave discharged batteries in the product.

Replace batteries in laser receiver

Battery compartment is located on the back side of laser receiver.

Remove battery cover, take out discharged batteries and install new

ones, observing correct polarity. Put battery cover back.

Use alkaline AAA batteries only. Remove the batteries from laser

receiver if it is not used for a long period of time to avoid corrosion and

battery discharging. All batteries should be replaced simultaneously.

All batteries should be of the same type and brand with the same

charge level.

Replace batteries in remote control

Battery compartment is located on the back side of remote control.

Remove the battery cover: slide out the battery cover and remove it.

Insert the batteries, observing correct polarity. Slide the cover back

until a click is heard.

Use alkaline AAA batteries only. Remove the batteries from remote

control if it is not used for a long period of time to avoid corrosion and

battery discharging. All batteries should be replaced simultaneously.

All batteries should be of the same type and brand with the same

charge level.
