7
English
Noise
information
Always wear ear protection if the sound
pressure exceed 85 dB(A).
Declaration of
conformity
We declare under our sole responsibility that the
product described under "Power tool specications" is
in conformity with all relevant provisions of the
directives 2006/95/EC, 2004/108/EC including their
amendments and complies with the following
standards: EN 60335-1, EN 60335-2-45, EN 62233.
Managing director V.Kobzar
Merit Link International AG
Switzerland
Stabio, 29.09.2015
General
safety recommendations
CAUTION! Make sure you have read
and understood all recommendations.
Failure to observe the following recom-
mendations may result in electric shock,
cause re and / or serious injuries. The term
"power tool", used in this manual refers to the
tools equipped with a power supply cord or a
battery.
Working space
• The workstation should be kept tidy and well-lit.
Disorder at the workstation and inadequate lighting
may result in accidents.
• Do not use power tools in environment exposed
to the risk of explosion, e.g. near ammable liquid
vapours, gases or ammable particles in the form of
dusts. During operation, sparks are generated, which
may ignite dust or vapours.
• Do not allow children and unauthorised persons
near places where operations with the use of an elec-
tric tool are carried out. Third parties may distract the
operator's attention, and he may loose control over the
tool.
Electric safety recommendations
• The tool plug should always be inserted to an
appropriate socket. This reduces the risk of electric
shock. Do not use plug adapters with grounding
contacts.
• Avoid touching grounded items, such as metal pipes,
heaters, cookers and refrigerators. If the worker's body
comes into contact with a grounded item, the danger of
electric shock increases.
• Protect the power tool against rain and moisture.
Penetration of water into the tool increases the danger
of electric shock.
• Do not use the power supply cable for purposes
other than designed. Under no circumstances should
one use the cable to carry the tool or pull it; also, it is
forbidden to switch off the tool by pulling the power
supply cable. Protect the cable against heating, contact
with kerosene-based bodies, with sharp edges or
mobile parts of the tool. A power cable that is damaged
or spliced increases the danger of electric shock.
Power tool specications
Hot air gun HLP16-500 HLP20-600 K
Power tool code
[127 V ~50/60 Hz]
[230 V ~50/60 Hz]
see page 6
Rated power at voltage (stage 1 / 2 / 3)
127 V [W]
230 V [W]
750 / 1500
900 / 1600
55 / 55-600 / 110-1600
150 / 150-1900 / 250-2000
Amperage at voltage
127 V [Amps]
230 V [Amps]
12.5
7
12.5
8.6
Temperature at voltage (stage 1 / 2 / 3)
127 V [°C]
230 V [°C]
350 / 500
350 / 500
50 / 50-450 / 50-600
50 / 50-600 / 50-600
Air ow (stage 1 / 2 / 3) [l/min] 300 / 500 350 / 350 / 500
Weight
[kg]
[lbs]
0,5
1.1
0,8
1.76
Safety class
Sound pressure [dB(A)] 85 85
Acoustic power [dB(A)] 98 104
Weighted vibration [m/s
2
] 7,9 8,2
