MAINTENANCE
English – 83
Battery
The battery is a safety switch and must only be mounted
on the engine when the machine is in use.
The battery is an intelligent 10.8V lithium battery that
must be activated before being used for the first time.
Place the battery into the charger and wait until at least 1
green lamp comes on (10 seconds). The battery can then
be mounted on the engine.
Charge the battery.
The battery has an easy-check voltage indicator with
LEDs (1-4).
If the voltage is too low (1 or 0 LEDs lit), place the battery
in the charger and connect to a wall socket (220V, 50Hz).
A flat battery will be fully charged after about 60 minutes.
The battery can be quick-charged for shorter periods
without damage.
Spark plug
• If the machine is low on power, difficult to start or runs
poorly at idle speed: always check the spark plug first
before taking other steps.
• If the spark plug is dirty, clean it and check that the
electrode gap is 0.7 mm. Replace if necessary.
Air filter
• Remove the air filter cover and take out the filter.
• Clean the filter by knocking the filter against a flat
surface. Never use solvent with petroleum, for
example, kerosene, or compressed air to clean the
filter.
• An air filter that has been in use for a long time cannot
be cleaned completely. The filter must therefore be
replaced with a new one at regular intervals.
A
damaged air filter must always be replaced.
• When reassembling, make sure that the filter
completely seals against the filter holder.
Fuel system
• Check that the fuel cap and its seal are not damaged.
• Check the fuel hose. Replace if necessary.
Recycling
This machine has the prerequisites to last for many years.
This minimizes the machine's environmental impact.
Perform service and maintenance according to the
instructions in this manual. This way the engine will last
longer and the hazardous emissions are minimized. The
machine is dismantled and the parts are divided up in
different materials for recycling. Most parts of this
machine are recyclable.
IMPORTANT! An exhausted battery must not be
disposed of as household garbage! Leave it at your
nearest service agent or collection point.
IMPORTANT! The battery on this model is a safety
component. Always use genuine parts.
Lamp indicator on
battery.
Cause
Constant red light Battery charging.
Flashing red light
Battery too warm and will start
to charge when correct
temperature has been reached.
Constant green light The battery is fully charged.
Flashing red and
green light
Battery damaged and must be
replaced.
NOTICE! Always use the recommended spark plug
type! Use of the wrong spark plug can damage the
piston/cylinder.
