Kenwood KMM-157 [12/52] Audio settings

DISPLAY (for

KMM-257

KMM-157

)

DISP DIMMER

ON: Dims the display illumination. ; OFF: Cancels.

TEXT SCROLL AUTO/ ONCE: Selects whether to scroll the display information automatically, or scroll only once. ;

OFF: Cancels.

AUDIO SETTINGS

While listening to any source...

1 Press the volume knob to enter

[FUNCTION]

2 Turn the volume knob to select

[AUDIO CTRL]

, then press the knob.

3 Turn the volume knob to make a selection (see the following table), then press the knob.

Repeat step 3 until the desired item is selected or activated.

4 Press and hold to exit.

• To return to the previous hierarchy, press .

Default:

SUB-W LEVEL –15 to +15 (0): Adjusts the subwoofer output level.

BASS LEVEL –8 to +8 (0):

Adjusts the level to memorize for each source. (Before making an adjustment,

select the source you want to adjust.)

MID LEVEL –8 to +8 (0):

TRE LEVEL –8 to +8 (0):

EQ PRO

BASS ADJUST BASS C FRQ 60/ 80/ 100/ 200: Selects the center frequency.

BASS LEVEL –8 to +8 (0): Adjusts the level.

BASS Q FCTR

1.00/ 1.25/ 1.50/ 2.00: Adjusts the quality factor.

BASS EXTEND ON: Turns on the extended bass. ; OFF: Cancels.

MID ADJUST MID C FRQ 0.5K/ 1.0K/ 1.5K/ 2.5K: Selects the center frequency.

MID LEVEL –8 to +8 (0): Adjusts the level.

MID Q FCTR 0.75/ 1.00/ 1.25: Adjusts the quality factor.

TRE ADJUST TRE C FRQ 10.0K/ 12.5K/ 15.0K/ 17.5K: Selects the center frequency.

TRE LEVEL –8 to +8 (0): Adjusts the level.

DISPLAY SETTINGS
