11
ENGLISH |
PRESET EQ NATURAL/ USER/ ROCK/ POPS/ EASY/ TOP40/ JAZZ/ POWERFUL: Selects a preset equalizer
suitable to the music genre. (Select [USER] to use the customized bass, middle, and treble
settings.)
BASS BOOST
B.BOOST LV1/ B.BOOST LV2/ B.BOOST LV3: Selects your preferred bass boost level. ;
OFF: Cancels.
LOUDNESS
LOUD LV1/ LOUD LV2: Selects your preferred low and high frequencies boost to produce a well-
balanced sound at a low volume level. ; OFF: Cancels.
BALANCE L15 to R15 (0): Adjusts the left and right speaker output balance.
FADER R15 to F15 (0): Adjusts the rear and front speaker output balance.
SUB-W SET ON: Turns on the subwoofer output. ; OFF: Cancels.
DETAIL SET
LPF SUB-W THROUGH: All signals are sent to the subwoofer. ; 85HZ/ 120HZ/ 160HZ: Audio signals with
frequencies lower than 85 Hz/ 120 Hz/ 160 Hz are sent to the subwoofer.
SUB-W PHASE REV (180°)/ NORM (0°): Selects the phase of the subwoofer output to be in line with the speaker
output for optimum performance. (Selectable only if a setting other than [THROUGH] is selected
for [LPF SUB-W].)
SUPREME SET ON: Creates realistic sound by interpolating the high-frequency components that are lost in audio
compression. ; OFF: Cancels. (Selectable only when playing back a USB device.)
VOL OFFSET
(Default: 0)
–8 to +8 (for AUX) ; –8 to 0 (for other sources): Presets the volume adjustment level of each
source. (Before adjustment, select the source you want to adjust.)
•
[SUB-W LEVEL]
/
[SUB-W SET]
/
[LPF SUB-W]
/
[SUB-W PHASE]
is selectable only if
[SWITCH PRE]
is set to
[SUB-W]
. (➜
5
)
•
[SUB-W LEVEL]
/
[LPF SUB-W]
/
[SUB-W PHASE]
is selectable only if
[SUB-W SET]
is set to
[ON]
.
AUDIO SETTINGS
EN_KMM-357SD[EN]3.indd 11EN_KMM-357SD[EN]3.indd 11 11/27/12 11:52:58 AM11/27/12 11:52:58 AM
