CIRCULAR SAWS

Description

The electric circular saw consists of a base, a cutting unit and a drive. The cutting unit is hinged on the base, that

allows you to adjust the depth and angle of the cut. The drive of the cutting unit is an AC collector motor, located

in the housing made of high-strength plastic.

To ensure safety, the machine is equipped with a movable protective cover which closes saw blade. The power

indicator showing readiness to turn on the engine is available. The switch key is equipped with a lock, it reduces

the risk of accidental activation.

OPERATION

ATTENTION!

Always disconnect the power cable from the electrical outlet before preparing for the operation,

adjustment, maintenance of the power tool.

ATTENTION!

After transporting in winter conditions, before switching on, the machine must be kept at room

temperature until the condensate is completely dry.

Circular Saw Assembly

The circular saw is supplied assembled. To install the saw blade onto the saw, take the protection away with the handle

1 (рiс. 1). Press the spindle lock button 15 (рiс.1) and hold it. Then, using the included hex key, remove the screw

13 (рiс. 1) and remove the outer ange of disk mounting 12 (рiс. 1).

Install the saw blade on the inner ange so that the direction of the arrow indicating the direction of rotation

on the disk, coincides with the direction of the arrow on the saw casing. Make sure the disc is installed on the ange

without gap and does not move in the radial direction. Install the outer ange and secure it with a screw 13 (рiс. 1),

previously pressing and holding the spindle lock button. Make a test of the saw, make sure there is no vibration.

Adjusting the depth and angle of cut

Turn the lever 20 (рiс. 1) counterclockwise about its axis to adjust the depth of cut. Holding the saw by the main

handle 18 (рiс. 1) and focusing on the scale 19 (рiс. 1) set the required cutting depth, moving down the back of the saw

foot. When sawing sheet material it is recommended to set the cutting depth to the appropriate thickness

of the work piece plus 5 ... 7 mm. Fix the selected cutting depth, tightening the lever 20 (pic. 1) by turning

it clockwise.

To adjust the angle of inclination turn the tilt adjustment screw 8 (рiс. 1) counterclockwise and focusing on the scale 7

(рiс. 1), set the desired angle of inclination by moving the support sole. Lock the selected position by tightening

the screw 8 (pic. 1) turning it clockwise.

Power connection

ATTENTION!

Before power connection, ensure the integrity of the product, no external damage. Pay special

attention to the reliability of the mounting of saw blade and the tightening of the screw of the disk

mounting.

Make sure the power switch is in the o position.
