9
CIRCULAR SAWS
EN
ATTENTION!
The electric tools should be connected only to the single phase AC which voltage corresponds
to the voltage indicated on the table of characteristics, placed on the tool housing. If the rating
plate indicates the voltage of 230V, then the power tool can also be switched on to a network
with a voltage of 220V.
When working outdoors use industrial extension cords intended for outdoor use. Do not use homemade
extensions. When working outdoors connect power tools to the power circuit equipped with a dierential automatic
with a response current of not more than 30 мА, this will reduce the risk of electric shock. When connecting ensure
that the insulation of the electrical cable and the power plug of the machine is intact.
Make sure the machine's power switch is in the “o” position. This power tool can be connected to power outlets
that do not have a protective ground, since it has double insulation (protection class II).
When connected to power, regardless of the position of the engine switch, the indicator 4 (рiс. 1) indicating
the readiness of the instrument to work should be lit.
Circular saw start
ATTENTION!
To avoid damage to the tool make sure that the disk is not in contact with the workpiece before
switching on the engine.
To turn on the saw press and hold the lock button 17 (рiс. 1) then press the switch key 16 (рiс.1). Consider that
a jerk may occur when the engine is turned on. To turn o the engine release the switch 16 (рiс. 1).
Turning on laser pointer
To improve comfort and ease the layout of the workpiece, the product is equipped with a laser pointer of the intended
line of cutting. To turn the pointer on press the button 4 (рiс. 1), located at the top of the main handle. To turn
the pointer o press the button 4 (рiс. 1) again.
ATTENTION!
To avoid damage do not point the laser pointer light to the eyes.
While working
•
Turn on the circular saw only if there is no contact between the saw blade and the workpiece. Allow the engine to reach
its maximum speed, only then smoothly cut into the material being processed, controlling the direction of the cut;
•
Hold the saw straight with both hands on the handles when cutting, tightly pressing the guide sole to the surface
of the material being cut. Watch for uniform feed, lack of lateral forces and disk jamming;
•
When performing long straight cuts of sheet material (plywood, wood boards) it is recommended to use a parallel
guide from the delivery set or a flat even object, clamped to the workpiece. This will increase the quality
of the cut and reduce the risk of disc jamming.
•
Remove the disc from the cut after it stops. In case of disk jamming in a cut turn o the saw and completely remove
the blade from the cut. If this fails, unplug the saw from the power supply and free the disc, slightly wedge the cut;
•
If in the process scraps hit the gap between the disc and the casing, disconnect the saw from the power supply
and remove the trim with a wire hook;
•
Avoid impacts to the saw body, as well as falling the saw on hard surfaces;
•
Protect the saw from external heat sources, as well as from the ingress of liquids and foreign objects inside;
•
Ensure eective saw cooling and removal of machining products from the cutting zone. Do not block or obstruct
the hole for ejection of sawdust in the xed case and ventilation openings in the machine housing;
•
Control the heating of the gearbox and the electric motor, monitor the condition of the saw blade. In case
of destruction of disc blades or breakage of teeth replace saw blade in a timely manner.
