10
CORDLESS MULTIFUNCTIONAL TOOL
EN
Plug the charger into wall outlet. In 1…2 s indicator 16 (pic. 1) of the charger glows green, which indicates
readiness for work.
Install the rechargeable battery into the charger guides until it stops, do not put much eort. If the battery is not instal-
led on the charger without much eort, check that the charger and battery match the rated voltage and model.
If the battery is low or not fully charged, charger indicator 16 (pic. 1) will change the color of the glow from
green to red, which indicates the ongoing process of charging. Battery indicator 12 (pic. 1) will ash, reecting
the charging process.
Upon reaching full battery charge the charger indicator 16 switches to green, the indicator on the battery
will glow without blinking.
ATTENTION!
Battery charging is possible at ambient temperatures from 0 °С to +40 °С. DO NOT charge the bat-
tery when the ambient temperature is negative.
NOTE. Remember to turn o the charger when charging is complete.
Your tool is equipped with a lithium-ion rechargeable battery which does not have memory eect. Batteries
of this type are rechargeable.
Keep the battery charged at a temperature not lower than 0 °С.
NOTE. New battery can reach its rated capacity after two or three charge-discharge cycles.
Battery charge level can be estimated using the indicator 12 (pic. 1) located on the battery case. The indicator turns
on when you press the button 11 (pic. 1) and turns o automatically after 3..4 sec. The glow of the three elements
of the indicator indicates a full battery, if glows one then the charge is about 30% and it is time to charge the battery.
Turn on the machine and adjust the oscillation frequency
To turn o the engine of the machine, turn the power switch 3 (piс. 1) to the "on" / "I" position pushing it forward
towards the actuator housing.
ATTENTION!
The machine has electronic engine control with soft start function. When you turn it on,
you must wait for the engine to develop its maximum speed, after which start processing.
Release the switch 4 (рiс. 1) to shut o the machine engine or, if the key is xed, click on its back ribbed part.
Use the regulator 5 (рiс.1) to adjust the frequency of the oscillations. Choose the frequency of oscillations
depending on the material being processed and the type of the tooling used. Consider that too high oscillation
frequency can lead to burning or melting of the processed material. The optimum frequency of oscillations
is determined empirically. The numbers printed on the ring of the regulator reect only the position of the regulator
and do not indicate a specic frequency of oscillations, expressed in units per minute.
Before using you must:
•
after transportation in winter conditions, before switching on, keep the machine at room temperature until
the water condensation is completely dry;
•
wipe the exterior of the machine with a cloth;
•
check the charger supply voltage. The power supply voltage must match the value indicated on the charger label;
•
check the compliance of the rated voltage of the machine with the rated voltage of the battery. Using a battery
with a higher rated voltage will damage the machine;
•
wear personal protective equipment (glasses, headphones, gloves) before starting work, set the tool in a comfor-
table position, take a steady position;
•
try the machine at idle.
While working:
•
after turning on the engine, let the machine develop the set speed of the tooling and only after that enter
the tooling and the workpiece into contact.
