![Festool OF 2200 EB-PLUS 574260 Инструкция по эксплуатации онлайн [14/116] 8166](/views2/1008826/page14/bge.png)
14
Router OF 2200
Table of contents
1 Symbols 14
2 Technical data 14
3 Machine features 14
4 Intended use 14
5 Safety instructions 14
5.1 General safety instructions 14
5.2 Machine-related safety instructions 14
5.3 Emission levels 15
6 Commissioning 15
7 Adjustments 15
7.1 Electronics 15
7.2 Changing tools 16
7.3 Changing the clamping collet 16
7.4 Adjusting the routing depth 16
7.5 Preliminary/Fine routing 17
7.6 Fine adjuster for edge trimming 17
7.7 Dust extraction 17
8 Operation 18
8.1 Machine guidance methods 18
8.2 Changing the base runner 19
8.3 Aluminium processing 19
9 Accessories 19
10 Service and maintenance 20
11 Disposal 20
12 Warranty 20
13 EU Declaration of Conformity 20
The specifi ed illustrations can be found at the
beginning an at the end of the operating instruc-
tions.
1 Symbols
Warning of general danger
Read the operating instructions/notes!
Wear a dust mask!
2 Technical data
Power 2200 W
(110 V-Version: 16 A)
Rotational speed (no load) 10000 - 22000 rpm
Quick depth adjustment 80 mm
Fine depth adjustment 20 mm
Connecting thread on drive shaft M 22 x 1.0
Max. routing tool diameter 89 mm (3½")
Weight (without mains cable) 7.8 kg
Protection class
/ II
3 Machine features
[1.1] Adjusting wheel for fi ne routing depth ad-
justment
[1.2] Dial ring for fi ne routing depth adjust-
ment
[1.3] Rotary knob for fi xing routing depth
[1.4] Scale for routing depth
[1.5] Depth stop with indicator
[1.6] Clamp lever for depth stop
[1.7] Eccenter for connecting depth stop and
stepped stop
[1.8] Stepped stop
[1.9] Lever for changing base runner
[1.10] Rocker switch for spindle lock
[1.11] Adjusting wheel for speed control
[2.1] Locking knob for on/off switch
[2.2] On/off switch
[2.3] Lever for locking protective guard
[2.4] Handles
[2.5] Extractor connector
4 Intended use
The routers are designed for routing wood, plas-
tics and materials similar to wood. The routing
tools included in Festool sales documents are
also suitable for routing aluminium and plaster-
board.
The user bears the responsibility for damage and
accidents caused by improper use.
5 Safety instructions
5.1 General safety instructions
WARNING! Read all safety warnings and all
instructions. Failure to follow the warnings
and instructions may result in electric shock, fi re
and/or serious injury.
Save all warnings and instructions for future
reference.
The term „power tool“ in the warnings refers to
your mains-operated (corded) power tool or bat-
tery-operated (cordless) power tool.
5.2 Machine-related safety instructions
Ensure that the router bit is seated fi rmly and -
that it runs perfectly.
The clamping collet and locking nut must not -
show any signs of damage.
Only use tools that meet standard EN 847-1. All -
Festool routing tools fulfi l these requirements.
