19
Remove the base runner [14.1]. f
Release the lever [14.4] again. f
Insert a copying ring [14.3] in the correct posi- f
tion on the router base.
Insert the tabs [14.2] on a base runner into the f
router base.
Push down the base runner until it engages in f
the router base.
The overhang Y of the workpiece in relation the
template [Fig. 15] is calculated as follows:
Y = ½ (diameter of copying ring minus diameter of
routing bit)
c) Edge trimming
Routing tools with a bearing guide are required
when the machine is used for edge trimming. The
machine is then guided in such a way that the
bearing guide rolls off the workpiece.
When trimming edges, always use the chip defl ec-
tor KSF-OF to improve dust extraction.
d) Routing with a guide system FS
The guide system (partly as an accessory) makes
it easier to route straight grooves.
Secure the guide rail to the workpiece using f
clamps [16.4].
Insert the base runner [16.3] for the guide stop f
into the router base (see "Changing the base
runner").
This base runner is offset to compensate for
the height of the guide rail.
Secure both guide rods [16.6] with the rotary f
knobs [16.5] and [16.9] on the guide stop.
Unscrew the rotary knob [16.1]. f
Insert the guide rods [16.6] into the grooves on f
the router base.
Place the router with the guide stop on the f
guide rail.
If required, you can adjust the play of the guide f
stop on the guide rail by adjusting the two guid-
ance jaws [16.2] with a screwdriver.
Slide the router along the guide rods until the f
routing tool reaches the required distance X
from the guide rail.
Screw up the rotary knob [16.1]. f
Unscrew the rotary knob [16.10]. f
Turn the adjusting wheel [16.7] to adjust dis- f
tance X more precisely.
Hold the adjusting wheel [16.7] to turn the
scale [16.8] independently to "zero".
Screw up the rotary knob [16.10]. f
8.2 Changing the base runner
Festool offers special base runners (as an acces-
sory) for different applications.
Change the base runner as follows:
Lay the machine on its side on a stable base. f
Open the lever [14.4]. f
Remove the base runner [14.1]. f
Release the lever [14.4] again. f
Insert the tabs [14.2] on a base runner into the f
router base.
Push down the base runner until it engages in f
the router base.
Before using the base runner: remove the protec-
tive foil!
8.3 Aluminium processing
WARNING
Risk of accident - always perform the following
safety measures when routing aluminium:
Add a residual-current circuit-breaker (FI, f
PRCD).
Connect the machine to a suitable dust ex- f
tractor.
Remove dust deposits from the motor hous- f
ing on a regular basis.
Wear protective goggles. f
9 Accessories
Use only original Festool accessories and Festool
consumable material designed for this machine
because these components are designed specifi -
cally for the machine. Using accessories and con-
sumable material from other suppliers will most
likely affect the quality of your working results
and limit any warranty claims. Machine wear or
your own personal workload may increase de-
pending on the application. Protect yourself and
your machine, and preserve your warranty claims
by always using original Festool accessories and
Festool consumable material!
Festool offers you a comprehensive range of ac-
cessories for your router:
Routing tools for different applications. -
Guide rails for straight routing. -
Runner bases for different applications. -
