Electric Lawn Mower EN
1110
INTENDED USE
This product is intended for domestic lawn
mowing.
ASSEMBLY
IMPORTANT! Before you assemble
the lawn mower, check the accessories
according above information, make sure the
accessories are completed.
1. FITTING THE HANDLE (See Fig. A1,
A2, A3)
Remove the screws (X 2) on the both side of
poles.
1) Insert the lower handle (8) into the holes
provided.
2) Secure with the screws (See Fig. A1).
3) Attach the upper handle (6) with the bolts
and handle knobs (7) to the lower handle
(8) (See Fig. A2).
NOTE: Ensure the bolts are fully inserted
through the handles before fitting the handle
knobs.
Attach the cable clips (3) provided, to the
upper and lower handle. Insert the cable into
the clips ensuring there is enough cable slack.
(See Fig. A3)
2. GRASS COLLECTION BAG ASSEMBLY
Connect the grass box handle to the box top
as shown in Fig. B1-B4.
1) Press the front of the handle briefly (See
Fig. B2).
2) Then push it forward (See Fig. B2).
3) Push down the back of the handle (See Fig.
B2).
4) Finally, clip the plastic clips over the metal
frame (See Fig. B3).
WARNING: Don’t fit the handle in
reversed direction. Fit the handle as
shown in Fig B1.
3. GRASS COLLECTION BAG FITTING
(See Fig. C1, C2, C3)
1) Turn the mower off, wait until blade stops.
2) Raise the safety flap (9) and hold it up
3) Pick up the grass bag by the handle, and
position grass bag on the lower hooks (a)
on the mower deck ( See Fig. C2).
4) Release the safety guard to lock the grass
bag into position. Ensure the grass bag is
installed securely ( See Fig. C3).
NOTE: Depress the grass bag slightly to
ensure that it is completely installed.
4. REMOVING/EMPTYING
Lift the safety flap (9) and hold up. Remove
grass collection bag (5).
WARNING! Always check the safety flap
can close the discharge outlet tightly
before using. Never lift the safety flap (9)
when the lawn mower is being used without
fitted grass collection bag.
OPERATION
1. STARTING AND STOPPING (See Fig.
D1, D2)
STARTING
Connect the female extension cable connector
to the pigtail. Connect the plug to the mains
and switch ON.
The switch box is provided with a lock-
off button to prevent accidental starting.
With one hand press and hold the safety
button (D1), with the other hand squeeze the
switch lever (D2) towards the handle, and
release the safety lock-off button. The machine
is now started, wait until the product is at full
speed before cutting the grass. Then use both
y our hands to hold the switch lever to keep it
running.
STOPPING
Release the switch lever.
2. ADJUSTING THE CUTTING HEIGHT
(See Fig. E)
WARNING! Before adjusting the
mower height, wait for the mower to
completely stop. Mower blades continue to
rotate after the machine is switched off and
a rotating blade can cause injury. Wait until
all machine components have completely
stopped before touching them.
Before your first cut, adjust the mower cutting
depth to the desired position. The lawnmower
can be set to 3 cutting heights between 20mm
and 60mm.
