GB
- 17 -
4. Technical data
Idling speed n
0
........................ 8,000-13,000 rpm
Air speed ................................................ 210 kph
Suction power ....................................... 720 m
3
/h
Volume of catch bag .................. approx. 45 liters
Sound volume level L
WA
.................... 92.68 dB(A)
Uncertainty K ........................................ 3 dB (A)
Sound pressure level L
pA
.................... 83.1 dB(A)
Vibration ahv ....................................... 2.354 m/s
2
Uncertainty K ..........................................1.5 m/s
2
Weight ........................................................3.3 kg
Important!
The equipment is supplied without batteries and
without a charger is allowed to be used only with
the lithium-ion batteries of the Power-X-Change
series!
Power-X-Change
18 V, 1.5 Ah .............................. 5 lithium-ion cells
18 V, 2.0 Ah .............................. 5 lithium-ion cells
18 V, 3.0 Ah ............................ 10 lithium-ion cells
18 V, 4.0 Ah ............................ 10 lithium-ion cells
18 V, 5.2 Ah ............................ 10 lithium-ion cells
The lithium-ion batteries of the Power-X-Change
series are allowed to be charged only with the
Power-X charger.
Charger
Mains voltage ....................200-250 V ~ 50-60 Hz
Output
Rated voltage ........................................ 21 V d. c.
Rated current .......................................3,000 mA
Keep the noise emissions and vibrations to a
minimum.
•
Only use appliances which are in perfect wor-
king order.
•
Service and clean the appliance regularly.
•
Adapt your working style to suit the appliance.
•
Do not overload the appliance.
•
Have the appliance serviced whenever ne-
cessary.
•
Switch the appliance off when it is not in use.
•
Wear protective gloves.
Caution!
Residual risks
Even if you use this electric power tool in
accordance with instructions, certain resi-
dual risks cannot be rules out. The following
hazards may arise in connection with the
equipment’s construction and layout:
1. Lung damage if no suitable protective dust
mask is used.
2. Damage to hearing if no suitable ear protec-
tion is used.
3. Health damage caused by hand-arm vib-
rations if the equipment is used over a pro-
longed period or is not properly guided and
maintained.
5. Before starting the equipment
The equipment is supplied without batteries
and without a charger.
Warning!
Always remove the batteries before making
adjustments to the equipment.
5.1. Mounting the suction tube (Fig. 3a-3f)
•
Plug together the front and rear suction tube
(Fig. 3a) and secure with the screw (Fig. 3b/
Item 12).
•
Now slide the complete suction tube into the
motor housing (Fig. 3c) and secure with the
screws (Fig. 3d/ Item 12).
•
Fit the two wheels (Fig. 3e/Item 9) into the
wheel support (Fig. 3e/ Item 11). Make sure
that there is an audible click when they en-
gage.
•
Slide the wheel support (Fig. 3f/Item 11) onto
the front suction tube as far as the stop (Fig.
3f/Item D) and secure with the screw (Fig. 3f/
Item 13).
Note: Please note that the two vacuum tubes
must always be joined together before they
are mounted on the motor housing, and that
they must never be taken apart when moun-
ted!
5.2. Mounting the catch bag (Figs. 4-5)
Hang the hook on the suction tube (Fig. 4A) and
on the housing (Fig. 4b). Then slip the catch bag
over the socket on the motor housing; it engages
correctly when it makes an audible click (Fig. 5).
Anl_GE_CL_36_Li_E_Solo_SPK7.indb 17Anl_GE_CL_36_Li_E_Solo_SPK7.indb 17 22.03.16 09:0222.03.16 09:02
