11

RAK110

4.4. Check that the power button in the cover is on down position and also the switch pin on the thermo-

stat is on down position (1).

4.5. Install the frame and carefully press the cover with display onto the thermostat. Place the upper part

(2) rst and then press the lower part (3) to its place.

4.6. Conrm the placement by carefully pushing the cover onto the thermostat (4).

4.7. Start the thermostat by switching the power button on the thermostat to up position (5).

Warning! Do not apply pressure to the corners of the display cover or to the display itself.

6. OPERATION

6.1. The thermostat starts when ON/OFF switch is in up position. In down position the thermostat is o.

6.2. First connection will start an installer Wizard which will setup the device.

Region: Select time region

Language: Select language which the thermostat will use

Date: Set the current date dd.mm.yyyy

Time: Set the current time hh:mm

Floor type: Select “Tile oor” or “Wooden oor”

Conrm the settings with or discard with

NOTE! The thermostat is equipped with a sensitive touch screen. Tap the touch screen with ngertips lightly.
