5.4. The adjustment range can be limited with the limiters of the adjustment knob (pic 7).

5.5. When thermostat is functioning normally, a faint click is heard when the load is switched on and o.

6. TECHNICAL DATA

ECO10R, ECO10F, ECO10FS and ECOINTRO10F

Supply voltage 230 V -15%, +10%, 50 Hz

Switch contact 2-pole

Operating temperature range -20 ... +30 °C

Temperature reduction xed –4 °C, control 230V

Signal light B

green: thermostat on, heating o

red: heating on

Floor sensor NTC, 47 kΩ at 25°C, cable 4 m (extendable to 10 m)

Floor sensor resistance values see page 2, table 1 (sensor not connected)

Circuit breaker/fuse max. 16A

Power in standby 5 W

Type Temp. range Nom. current (res.) Max load Protection class

ECO10R 5 - 35 °C 10A 2300W IP30

ECO10F 10 - 60 °C 10A 2300W IP31

ECO10FS 10 - 35 °C 10A 2300W IP31

ECOINTRO10F 10 - 60 °C 10A 2300W IP31

Thermostat can control external relay.

7. WARRANTY

The warranty period for Ensto ECO thermostats is 2 years from the date of purchase but no longer than 3

years from the date of manufacture. Warranty conditions, see the product card www.ensto.com.

8. ENVIRONMENTAL ASPECTS

The product’s cardboard packing is suitable for recycling.

When a heating system is at the end of the life cycle the cables, conduits and electronic compo-

nents must be disposed of properly according to local recycling guidelines.

9. PICTURES

1. Connection diagram

2. Connection of wires to the thermostat

3. User interface of the thermostat

4. Installation and uninstallation

5. Calibration of the adjustment knob

6. Temperature reduction xed -4°C

7. Limitation of adjustment range
