ENGLISHen
10
Empty (7) collection container:
Unscrew the collection container (7)
(counterclockwise) and remove rivet mandrels.
After approx. 5,000 riveting processes:
- Device maintenance is restricted to only the
chuck mechanism and its wear parts:
• Remove battery pack (11) from the device.
• Unscrew steel sleeve (5) with spanner wrench
(size 27) and clean. Check for deposits in the
tip of the steel (5) sleeve.
• Use (15) spanner wrench (size 17) to unscrew
cage for chuck jaws from the closure (hold in
place with size 15), remove (16) jaws, clean,
and oil or grease contact surfaces. If the parts
are worn (rivet can no longer be placed in one
step), replace (16) chuck jaws.
Order no.: 6.27355 Chuck jaws for NP 18
LTX BL 5.0
• Oil / grease o-ring (14) on the chuck jaw cage
(15)
• Pull out pressure bar (17) to the front and clean.
• Assemble in reverse order. Screw in all parts.
We recommend having the device maintained
by an authorised electrician or the Metabo
Service department at least every 2 years or
after 50,000 riveting processes. More frequent
maintenance is recommended for intensive
use.
f
Only use original Metabo battery packs and Metabo
accessories.
Use only accessories that fulfil the requirements
and specifications listed in these operating
instructions. Fit accessories securely.
Charger: ASC 30-36, etc
Battery packs with different capacities. Buy
battery packs only with voltage suitable for your
power tool.
Order no.: 6.25367 ....4.0 Ah (LiHD)
Order no.: 6.25596 .... 2.0 Ah (Li-Ion)
etc.
Repairs to electrical tools must ONLY be carried out
by qualified electricians!
Contact your local Metabo representative if you
have Metabo power tools requiring repairs. See
www.metabo.com for addresses.
You can download a list of spare parts from
www.metabo.com.
Observe national regulations on environmentally
compatible disposal and on the recycling of disused
machines, packaging and accessories.
Only for EU countries: never dispose of
power tools in your household waste!
According to European Directive 2012/96/EU
on Waste from Electric and Electronic Equipment
and implementation in national law, used power
tools must be collected separately and recycled in
an environmentally-friendly manner.
Discharge the battery pack in the power tool before
disposal. Prevent the contacts from short-circuiting
(e.g. by protecting them with adhesive tape).
f
Explanatory notes on the specifications on page 3.
Subject to change in accordance with technical
progress.
U = Voltage of battery pack
m = Weight (with smallest battery pack)
H = Total stroke
F = Setting force
D = Rivet diameter
Measured values determined in conformity with EN
62841.
Permitted ambient temperature during operation: -
20 °C bis 50 °C (limited performance with
temperatures below 0 °C). Permitted ambient
temperature for storage: 0 °C to 30 °C
direct current
The technical specifications quoted are subject to
tolerances (in compliance with the relevant valid
standards).
Explanatory notes on the specifications on page 2.
Aluminium
Steel
Stainless steel
Emission values
These values make it possible to assess the
emissions from the power tool and to compare
different power tools. The actual load may be higher
or lower depending on the operating conditions, the
condition of the power tool or the accessories.
Please allow for breaks and periods when the load
is lower for assessment purposes. Arrange
protective measures for the user, such as
organisational measures based on the adjusted
estimates.
Vibration total value (vector sum of three directions)
determined in accordance with EN 62841:
a
h
= vibration emission value
K
h
= Uncertainty
Typical A-effective perceived sound levels:
L
pa
= Sound-pressure level
K
pA
, = Uncertainty
During operation the noise level can exceed 80
dB(A).
Wear ear protectors!
9. Accessories
10. Repairs
11. Environmental Protection
12. Technical Data
ALU
