ENGLISH en

Your risk from these exposures varies, depending

on how often you do this type of work. To reduce

your exposure to these chemicals: work in a well

ventilated area, and work with approved safety

equipment, such as those dust masks that are

specially designed to filter out microscopic

particles.

This also applies to dust from other materials such

as some timber types (like oak or beech dust),

metals, asbestos. Other known diseases are e.g.

allergic reactions, respiratory diseases. Do not let

dust enter the body.

Observe the relevant guidelines and national

regulations for your material, staff, application and

place of application (e.g. occupational health and

safety regulations, disposal).

Collect the particles generated at the source, avoid

deposits in the surrounding area.

Use suitable accessories for special work. In this

way, fewer particles enter the environment in an

uncontrolled manner.

Use a suitable extraction unit.

Reduce dust exposure with the following measures:

- do not direct the escaping particles and the

exhaust air stream at yourself or nearby persons

or on dust deposits,

- use an extraction unit and/or air purifiers,

- ensure good ventilation of the workplace and keep

clean using a vacuum cleaner. Sweeping or

blowing stirs up dust.

- Vacuum or wash the protective clothing. Do not

blow, beat or brush.

See page 2.

1 Magazine for nosepieces

2 Nosepieces *

3 Button to activate / deactivate the LED light

4 LED light to illuminate the workplace

5 Steel sleeve

6 Mount (not for fall protection!)

7 Collection container for rivet bodies

8 Trigger

9 Handle

10 Battery pack release button

11 Battery pack *

12 Capacity indicator button *

13 Capacity and signal indicator *

14 O-Ring

15 Cage for chuck jaws

16 Chuck jaws (3 piece)

17 Pressure bar

*equipment-specific

Ventilation slots for the motor may not be kept

closed or covered; do not insert objects into

slots.

6.1 Screw on Nosepiece

Select nosepiece (2) to match rivet diameter (see

table on page 2) and screw in (see page 2, image

A).Blind rivet should have a little play in the

nosepiece (2), otherwise the blind rivet may

become stuck.

6.2 Attach Collection Container

Screw on collection container (7) for rivet bodies to

the stop (clockwise).

6.3 Battery pack

Charge the battery pack (11) before use.

Recharge the battery pack (11) if performance

diminishes.

Instructions on charging the battery pack can be

found in the operating instructions of the Metabo

charger.

Li-Ion battery packs "Li-Power, LiHD" have a

capacity and signal indicator (13):

- Press the button (12); the LEDs indicate the

charge (13) level.

- If one LED (13) is flashing, the battery pack (11) is

almost flat and must be recharged.

6.4 Removing and inserting the battery pack

Removing:

Press the battery pack release (10) button and

remove the battery pack (11).

Inserting:

Slide in the battery pack (11) until it engages.

7.1 Setting a Blind Rivet

Insert the mandrel of the blind rivet fully into the

attached nosepiece (2).

Press and Hold the Switch (8)

Pressing and holding the switch (8) triggers the

riveting process. The riveting process will stop once

the blind rivet is set. Broken rivet bodies (mandrels)

will be retained. Only after you release the switch

will the mandrel be ejected, and the device will

return to its initial position. The riveting process is

completed.

After finishing the riveting process, tip the

device back so that the mandrel falls into

the collection (7) container. Otherwise, you

may jam the device.

7.2 Switch on the LED light (4)

After pressing the pushbutton switch (8) the LED

lamp (4) can be activated and deactivated for 15

minutes by pressing the switch (3). The LED lamp

(4) automatically switches off after 60 seconds

(see illustration B on page 2).

Remove the battery pack before

completing any maintenance or cleaning

on the device!

5. Overview

6. Initial Operation

7. Use

8. Maintenance and Cleaning
