COMPONENT LIST
1.
AUXILIARY HANDLE
2. SPINDLE LOCK BUTTON
3. ON/OFF SWITCH
4. VARIABLE SPEED CONTROL
5. BATTERY PACK RELEASE BUTTON
6. BATTERY PACK*
7. WHEEL GUARD FOR GRINDING
8. DISC *
9. SPANNER
10. INNER FLANGE
11. OUTER FLANGE
12. CLAMP ADJUSTMENT NUT
13. SPINDLE
14.
GUARD CLAMPING LEVER
* Not all the accessories illustrated or
described are included in standard delivery.
TECHNICAL DATA
KU801 KU801.9
Rated voltage
20V
No load speed
3500/6000/8500/min
Disc size
125mm
Disc bore
22.2mm
Spindle thread
M14
Machine weight 2.4kg 1.7kg
ACCESSORIES
KU801 KU801.9
Spanner
1 1
Auxiliary handle
1 1
SDS wheel guard
1 1
Battery pack (KA3498)
2 /
Charger (KA3705)
1 /
We recommend that you purchase your accessories
listed in the above list from the same store that sold
you the tool. Refer to the accessory packaging for
further details. Store personnel can assist you and offer
advice.
OPERATING
INSTRUCTIONS
Note: Before using the tool, read the instruction
book carefully.
INTENDED USE
The machine is intended for cutting, roughing and
brushing metal and stone materials without using
water. For cutting metal, a special protection guard for
cutting (accessory) must be used.
ASSEMBLY AND
OPERATION
ACTION FIGURE
BEFORE OPERATION
Removing the battery pack See Fig. A1
Charging the battery pack See Fig. A2
Installing the battery pack
WARNING: When replacing
the battery pack, do not
insert the battery until the
Grinding/Cutting Disc comes to
a complete stop!
See Fig. A3
ASSEMBLY
Assembling Auxiliary Handle See Fig. B
Assembling Grinding/Cutting Disc
See Fig.
C1, C2, C3
Adjusting Wheel Guard
Note: Before any work on the
machine itself, remove the
battery pack. For work with
grinding or cutting discs, the
protection guard must be
mounted. Use the correct type
of disc for your application. If
the power tool is intended to
perform cutting off operations,
a guard specific for this
operation must be fitted.
The coded projection on the wheel
guard ensures that only a guard
that ts the machine type can be
mounted.
Open the clamping lever. Place the
wheel guard with coded projection
into the coded groove on the spindle
of the machine head and rotate
to the required position (working
position).
To fasten the wheel guard, close the
clamping lever.
The closed side of the wheel
guard must always point to the
operator.
See Fig. D
