English
Problem Possible Cause Corrective Action
Machine functions
intermittently
Extension cable damaged Inspect cable, replace if dam-
aged
Internal wiring of machine
damaged
Contact Service Agent
Worn/Missing tines/blades ALR 900:
Fit replacment (see “Remov-
ing/Fitting Raker Tines”)
AVR 1100:
Contact Service Agent
Conditions too wet Increase height of cut (see “Rak-
ing/Verticutting Tips”)
Too much debris on the ground See below*
Possible clogging Check underneath the machine
and clear out as necessary (al-
ways wear gardening gloves)
Raking/Verticutting too low for
the conditions
Increase height of cut
Grass too long Cut grass
Very uneven surface Increase height of cut
Grassbox full Empty the grassbox regularly
*In conditions with excessive tree debris (e. g. leaves, twigs, etc.) first clear the surface by using the
machine with a height of cut setting of either 3 or 4.
Machine labours or belt squeals Height of cut too low Increase height of cut (see “Ad-
justing the Cutting Height”)
Cutting tines/blades not rotat-
ing
Cutting tines/blades obstructed
by grass
Clear obstruction (always wear
gardening gloves)
Belt is slipping or is damaged Contact Service Agent
Excessive vibrations/noise
Cutting tines/blades damaged ALR 900:
Fit replacment (see “Remov-
ing/Fitting Raker Tines”)
AVR 1100:
Contact Service Agent
Poor collection
Raking/Verticutting in wet con-
ditions
Increase height of cut (see “Rak-
ing/Verticutting Tips”)
Raking/Verticutting too low for
the conditions
Increase height of cut
Possible clogging Check underneath the machine
and clear out as necessary (al-
ways wear gardening gloves)
Blocked side grilles Clear debris from the outside of
the side grilles
Missing tine springs (ALR 900
only)
Replace tine springs (always
wear gardening gloves)
Maintenance and Service
Maintenance and Cleaning
f Stop, remove plug from the power supply
and remove the grassbox.
f
Always wear gardening gloves when han-
dling or working near the sharp tines/blade.
Note: To ensure long and reliable service, carry
out the following maintenance regularly.
Regularly check for obvious defects such as
loose, dislodged or damaged tines/blades,
loose fixings, and worn or damaged compo-
nents.
Check that covers and guards are undamaged
and correctly fitted. Carry out necessary mainte-
nance or repairs before using.
If the machine should happen to fail despite the
care taken in manufacture and testing, repair
should be carried out by an authorised custom-
er service agent for Bosch garden products.
In all correspondence and spare parts orders,
please always include the 10-digit article
number given on the type plate of the machine.
Removing/Fitting Raker Tines
f Stop, remove plug from the power supply
and remove the grassbox.
f
Always wear gardening gloves when han-
dling or working near the sharp tines/blade.
G
Turn the machine over.
Use long-nose pliers to grip the tine 12, press
down and remove the tine 12 from the pin 11.
(see figure G)
The new tine 12 is mounted in reverse order.
After Raking or Verticutting/Storage
Clean the exterior of the machine thoroughly us-
ing a soft brush and cloth. Do not use water, sol-
vents or polishes. Remove all grass and debris,
especially from the ventilation slots 8.
Turn the machine on its side and clean the
tine/blade area. If grass or dirt is compacted in
the tine/blade area, remove with a wooden or
plastic implement.
f
Always wear gardening gloves when han-
dling or working near the sharp tines/blade.
Store the machine in a dry place. Do not place
other objects on top of the machine. To save
space, fold up the handle fully.
f
Ensure the cables are not trapped when
folding/unfolding top/bottom handles. Do
not drop the handles.
The machine can be stored with the grassbox
disassembled. (see figure H)
H
