(Original instructions) ENGLISH
7
Warning! If the power cord is damaged, it must be
replaced by the manufacturer, authorized Stanley
Service Center or an equally qualified person in
order to avoid damage or injury. If the power cord is
replaced by an equally qualified person, but not
authorized by Stanley, the warranty will not be valid.
Using an Extension Cable
If it is necessary to use an extension cable, please used an
approved extension cable that fits the tool’s power input
specifications. The minimum cross-sectional area of the
conducting wire is 1.5 sq. mm. Cables should be untangled
before reeling up.
Features (Fig. A)
This tool includes some or all of the following features.
1. ON/OFF Switch
2. Spindle Lock
3. Guard
Assembly
WARNING! To prevent accidental operation, turn off and
unplug tool before performing the following operations. Failure
to do this could result in serious personal injury.
Attaching and Removing the Wheel Guard (Fig. B)
WARNING! To minimize the danger of serious personal injury,
please switch off the tool power and disconnect all plugs
before adjusting or removing/installing any accessory. Before
reassembling the tool, press and release the trigger switch to
make sure the tool is already switched off.
Attaching the Guard
1. Place the angle grinder on a work bench, groove facing
up.
2. Bring the flange of the guard (3) collar over the groove (9)
of the gear housing.
3. Turn the guard (3) counterclockwise by 150 degrees.
4. Make sure that the screws (10) are tightened.
Removing the Guard
1. Loosen the screws (10) on the guard collar.
2. Pull up the guard (3).
WARNING! Do not operate the tool when the safety guard is
not in place.
Note: Refer to the grinding accessories chart at the end of this
section for accessories that can be used together with this
angle grinder.
Attaching and Removing Grinding Wheels (Fig. C
and D)
WARNING! Do not use damaged grinding wheels.
1. Place the tool on a work bench, groove facing up.
2. Figure C: Attach the inner ange (4) correctly on the
output shaft (5).
3. Place the grinding wheel (6) on the inner flange (4).When
attaching a grinding wheel with a raised center,make sure
that the raised center (7) faces the innerflange (4).
4. Figure D: Tighten the outer flange (h) until the output shaft
(5).
4). When attaching the grinding wheel, the ring on top ofthe
outer flange (8) must face the wheel.
5. Press the spindle lock (2) and prevent the spindle (4)from
rotating until it locks in place.
6. Use the pin spanner to tighten the outer flange (8).
Preparation Before Use
Attach the safety guard and appropriate abrasive or
grinding wheels. Do not use abrasive or grinding wheels
that are overly worn.
Make sure that the inner and outer flanges are attached
correctly.
Cable cross-sectional
area (mm
2
) Cable rated
current (Ampere)
Cable cross-sectional
area (mm
2
) Cable rated
current (Ampere)
0.75 6
1.00 10
1.50 15
2.50 20
4.00 25
Cable length (m)
7.5 15 25 30 45 60
Voltage Amperes Cable rated current (Ampere)
110-127 0 - 2.0 6 6 6 6 6 10
2.1 - 3.4 6 6 6 6 15 15
3.5 - 5.0 6 6 10 15 20 20
5.1 - 7.0 10 10 15 20 20 25
7.1 - 12.0 15 15 20 25 25 -
12.1 - 20.0 20 20 25 - - -
220-240 0 - 2.0 6 6 6 6 6 6
2.1 - 3.4 6 6 6 6 6 6
3.5 - 5.0 6 6 6 6 10 15
5.1 - 7.0 10 10 10 10 15 15
7.1 - 12.0 15 15 15 15 20 20
12.1 - 20.0 20 20 20 20 25 -
