GB
- 21 -
5.2 Replacing and adjusting the guard (Fig. 3)
Replacing:
•
Remove the flange nut (b) and the clamping
flange underneath.
•
Open the clamp lever (a) on the guard (4).
•
Turn the guard (4) through 180° in clockwise
direction so that the guard points upwards.
•
Remove the guard (4).
To mount, proceed in the reverse order.
Adjusting:
•
Adjust the guard (4) to protect your hands
so that the material being ground is directed
away from your body.
•
The position of the guard (4) can be adjusted
to any specific working conditions. Undo the
clamp handle (a) and turn the cover (4) into
the required position.
•
Ensure that the guard (4) correctly covers the
gear wheel casing.
•
Secure the clamp handle (a) again.
•
Ensure that the guard (4) is secure.
Warning!
Make sure that the guard is perfectly secure.
Warning!
Never use the angle grinder without the gu-
ard.
5.3 Test run for new grinding Wheels
Allow the right-angle grinder to run in idle for at
least 1 minute with the grinding or cutting wheel
fi tted in place. Vibrating wheels are to be replaced
immediately.
6. Operation
6.1 Charging the Li battery pack (Fig. 4-5)
1. Remove the battery pack (6) from the handle,
pressing the pushlock button (8) downwards
to do so.
2. Check that your mains voltage is the same as
that marked on the rating plate of the battery
charger. Insert the power plug of the charger
(7) into the mains socket outlet. The green
LED will then begin to fl ash.
3. Push the battery pack onto the battery char-
ger.
In section 10 (Charger indicator) you will fi nd a
table with an explanation of the LED indicator on
the charger.
If the battery pack fails to charge, check for the
following:
•
voltage at the power socket
•
whether there is good contact at the charging
contacts of the charging unit
If the battery pack still fails to charge, send
•
the charger and charging adapter
•
and the battery pack
to our customer service center.
To ensure that the Li battery pack provides
long service you should take care to recharge
it promptly. You must recharge the battery pack
when you notice that the power of the cordless
equipment drops.
6.2 Battery capacity indicator (Fig. 6/Item 9)
Press the battery capacity indicator switch (a).
The battery capacity indicator (9) shows the char-
ge status of the battery using 3 LEDs.
All 3 LEDs are lit:
The battery is fully charged.
2 or 1 LED(s) are lit:
The battery has an adequate remaining charge.
1 LED blinks:
The battery is empty, recharge the battery.
All LEDs blink:
The battery pack has undergone exhaustive di-
scharge and is defective. Do not use or charge a
defective battery pack.
6.3 Switching on (Fig. 7)
To start the equipment, push the On/Off switch
(2) forwards and press it down. To switch off the
angle grinder, depress the On/Off switch (2) at the
back. The On/Off switch (2) will jump back into its
starting position.
Important!
Wait until the machine has reached its top
speed. You can then position the angle grin-
der on the workpiece and machine it.
Anl_TE_AG_18_125_Li_BL_SPK9.indb 21Anl_TE_AG_18_125_Li_BL_SPK9.indb 21 24.04.2018 13:47:1624.04.2018 13:47:16
