12 | English
Intended Use
The power tool is intended for impact drilling in brick, con-
crete and stone, as well as for drilling in wood, metal,
ceramic and plastic. Tools with electronic control and right/
left rotation are also suitable for screwdriving and thread
cutting.
Product Features
The numbering of the product features refers to the diagram
of the power tool on the graphics page.
(1)
Keyless chuck
A)
(2)
Front sleeve
(3)
Rear sleeve
(4)
"Drilling/impact drilling" selector switch
(5)
Lock-on button for on/off switch
(6)
On/off switch
(7)
Speed preselection thumbwheel
(not applicable to tool model 3 601 B17 103)
(8)
Rotational direction switch
(9)
Button for depth stop adjustment
(10)
Wing bolt for auxiliary handle adjustment
(11)
Auxiliary handle (insulated gripping surface)
A)
(12)
Depth stop
A)
(13)
Drill chuck key
A)
(14)
Keyed chuck
A)
(15)
Universal bit holder
A)
(16)
Screwdriver bit
A)
(17)
Hex key
A)
(18)
Open-ended spanner
B)
(19)
Handle (insulated gripping surface)
A)
Accessories shown or described are not included with the
product as standard. You can find the complete selection of
accessories in our accessories range.
B)
Commercially available (not included in the scope of deliv-
ery)
Technical Data
Impact drill GSB 13 RE
Article number
3601B17 1..
Rated power input W 600
Max. power output W 301
No-load speed min
-1
0 – 2800
Rated speed min
-1
1570
Impact rate min
-1
44800
Rated torque Nm 1.8
Clockwise/anti-clockwise ro-
tation
●
Spindle collar diameter mm 43
Max. drilling diameter
Impact drill GSB 13 RE
– Masonry mm 15
– Concrete mm 13
– Steel mm 10
– Wood mm 25
Chuck capacity mm 1.5 – 13
Weight according to
EPTA-Procedure 01:2014
kg 1.8
Protection class
/ II
The specifications apply to a rated voltage [U] of 230 V. These spe-
cifications may vary at different voltages and in country-specific mod-
els.
Noise/vibration information
Noise emission values determined according to
EN62841-2-1.
Typically, the A-weighted noise level of the power tool is:
Sound pressure level 97dB(A); sound power level
108dB(A). Uncertainty K=5dB.
Wear hearing protection!
Vibration total values a
h
(triax vector sum) and uncertainty K
determined according to EN62841-2-1:
Drilling into metal: a
h
=4 m/s
2
, K=1.5 m/s
2
,
Impact drilling into concrete: a
h
=18.5 m/s
2
, K=3 m/s
2
,
Screwdriving: a
h
<2.5 m/s
2
, K=1.5 m/s
2
.
The vibration level and noise emission value given in these
instructions have been measured in accordance with a
standardised measuring procedure and may be used to com-
pare power tools. They may also be used for a preliminary
estimation of vibration and noise emissions.
The stated vibration level and noise emission value repres-
ent the main applications of the power tool. However, if the
power tool is used for other applications, with different ap-
plication tools or is poorly maintained, the vibration level
and noise emission value may differ. This may significantly
increase the vibration and noise emissions over the total
working period.
To estimate vibration and noise emissions accurately, the
times when the tool is switched off or when it is running but
not actually being used should also be taken into account.
This may significantly reduce vibration and noise emissions
over the total working period.
Implement additional safety measures to protect the oper-
ator from the effects of vibration, such as servicing the
power tool and application tools, keeping their hands warm,
and organising workflows correctly.
Assembly
u Pull the plug out of the socket before carrying out any
work on the power tool.
Auxiliary Handle (see figure A)
u Do not operate your power tool without the auxiliary
handle (11).
1 609 92A 53D | (05.11.2020) Bosch Power Tools
