5
EN
Kickback
Kickback is the upward and backward
movement of the saw blade when the saw blade
unexpectedly touches an object.
Securelyholdthemachineduringuse.
Keep your attention focused on the operation.
Kickback is usually caused by:
- unintentionally touching hard objects or
materials with the rotating saw blade;
- a blunt saw blade;
- a saw blade that is not properly mounted;
- sawing into a previous cut;
- a lack of attention to the operation;
- an instable stance.
ELECTRICAL SAFETY
Always check that the voltage of the
power supply corresponds to the voltage
on the rating plate.
• Donotusethemachineifthemainscableor
the mains plug is damaged.
• Onlyuseextensioncablesthataresuitable
for the power rating of the machine with a
minimum thickness of 1.5 mm
2
.Ifyouusea
extension cable reel, always fully unroll the
cable.
TECHNICAL DATA
Mains voltage 220-240 V~
Mains frequency 50 Hz
Power input 450 W
No-load speed 0-3.400/min
Max. sawing depth (wood) 65mm
Max. sawing stroke 6 mm
Mitre angle +45° - -45°
Number of pendulum positions 3+1
Weight 2.05 kg
NOISE AND VIBRATION
Sound pressure (L
pa
) 97.7 dB(A) K=3 dB(A)
Acoustic power (L
wa
) 108.6 dB(A) K=3 dB(A)
Vibration (wood) 11.015 m/s
2
K=1.5 m/s
2
Vibration (metal) 15.154 m/s
2
K=1.5 m/s
2
Wear hearing protection.
Vibration level
The vibration emission level stated in this
instruction manual has been measured in
accordance with a standardised test given in
EN 60745; it may be used to compare one tool
with another and as a preliminary assessment of
exposure to vibration when using the tool for the
applications mentioned
- using the tool for different applications, or with
different or poorly maintainted accessories,
may significantly increase the exposure level
- the times when the tool is switched off or when
it is running but not actually doing the job, may
signifi cantly reduce the exposure level
Protect yourself against the effects of vibration by
maintaining the tool and its accessories, keeping
your hands warm, and organizing your work
patterns
DESCRIPTION (FIG. A)
Your pendulum action jigsaw has been designed
for sawing wood, metal, plastics, ceramics,
rubber, etc. to any required size and in any
required shape.
1. On/offswitch
2. Lock-onbutton
4. Pendulum action switch
5. Guard
6. Sawbladeholder
7. Sawshoe
9. Dustextractionconnection
10. Grip
11. Allen key
ASSEMBLY
Before assembly, always switch off the
machine and remove the mains plug from
the mains.
Mounting and removing the saw blade (fig. B)
Refer to the table below to select the required saw
blade.
