3
ENGLISH
Explanation of general view
1-1. Button
1-2. Red part
1-3. Battery cartridge
2-1. Switch trigger
3-1. Lamp
4-1. Reversing switch
6-1. Chuck key
7-1. Chuck key holder
7-2. Screw
8-1. Groove
8-2. Hook
8-3. Screw
SPECIFICATIONS
Model BDA340 BDA350
Steel 10 mm 10 mm
Capacities
Wood 25 mm 25 mm
No load speed (min
-1
) 0 - 1,700 0 - 1,800
Overall length 314 mm 314 mm
Net weight 1.5 kg 1.6 kg
Rated voltage D.C. 14.4 V D.C. 18 V
• Due to our continuing programme of research and development, the specifications herein are subject to change without notice.
• Note: Specifications may differ from country to country.
ENE032-1
Intended use
The tool is intended for drilling in wood, metal and
plastic.
ENG101-1
For European countries only
Noise
The typical A-weighted noise level determined according
to EN60745-2-1:
Sound pressure level (L
pA
) : 73 dB(A)
Uncertainty (K) : 3 dB(A)
The noise level under working may exceed 85 dB (A).
Wear ear protection.
ENG202-1
Vibration
The vibration total value (tri-axial vector sum)
determined according to EN60745-2-1:
Work mode: Drilling into metal
Vibration emission (a
h,D
) : 2.5 m/s
2
or less
ENH102-7
EC-DECLARATION OF CONFORMITY
Model; BDA340, BDA350
We declare under our sole responsibility that this
product is in compliance with the following standards of
standardized documents;
EN60745, EN55014 in accordance with Council
Directives, 2004/108/EC, 98/37/EC.
CE2007
000230
Tomoyasu Kato
Director
Responsible Manufacturer:
Makita Corporation
3-11-8, Sumiyoshi-cho, Anjo, Aichi, JAPAN
Authorized Representative in Europe:
Makita International Europe Ltd.
Michigan Drive, Tongwell, Milton Keynes, Bucks MK15
8JD, ENGLAND
GEB002-2
SPECIFIC SAFETY RULES
DO NOT let comfort or familiarity with product
(gained from repeated use) replace strict adherence
to drill safety rules. If you use this power tool
unsafely or incorrectly, you can suffer serious
personal injury.
1. Hold power tools by insulated gripping
surfaces when performing an operation where
the cutting tool may contact hidden wiring or
its own cord. Contact with a "live" wire will make
exposed metal parts of the tool "live" and shock
the operator.
2. Always be sure you have a firm footing.
Be sure no one is below when using the tool in
high locations.
3. Hold the tool firmly.
4. Keep hands away from rotating parts.
5. Do not leave the tool running. Operate the tool
only when hand-held.
6. Do not touch the drill bit or the workpiece
immediately after operation; they may be
extremely hot and could burn your skin.
7. Some material contains chemicals which may
be toxic. Take caution to prevent dust
inhalation and skin contact. Follow material
supplier safety data.
SAVE THESE INSTRUCTIONS.
WARNING:
MISUSE or failure to follow the safety rules stated in
this instruction manual may cause serious personal
injury.
