Measurements Instruction

Measure AC/DC Voltage

1.Turn the rotary switch to or , then

choose AC or DC Voltage range.

2. Connect the black test lead to the COM

Terminal and the red lead to the Terminal.

3. Touch the probes to the correct test points of

the circuit to measure the voltage.

4. Read the measured voltage on the display.

Measure AC/DC Current

1.Turn the rotary switch to , then choose AC or

DC Current range.

2 . C o n n e c t t h e b l a c k t e s t l e a d t o t h e C O M

Terminal and the red test lead to the A (≤19.999A )or

mA (≤199.99mA).

• Do not measure voltage that exceeds the extremes

as indicated in the Specifications.

• D o n o t t o u c h h i g h v o l t a g e c i r c u i t d u r i n g

measurements.
