Apach ACB8840B (A) [3/6] Sl 140 new 2014

Page 3

Rev . 3 - 1 2/ 03 / 201 9

SL 140 NEW - 2014

COOLING SYSTEM

SL 140A / SL 140W / SL 140A DP

9 Air Condenser 20558

15 Sucking Fan 20031

Rif.

Descrizione Ricambio

Parts for Air-Cooled Version Only

Ref. Spare Description Code

8 Water Condenser 14374

Parts for Water-Cooled Version Only

Ref. Spare Description Code

220/240V 50 Hz 231202

220/230V 60 Hz 231308

Ref. 3 - Compressor

Voltage Code

1 Evaporator Cover Panel 10514

2 Evaporator Assy See Table

3 Compressor See Table

7* Solid Core Drier 14089

10 Sucking Fan 10213

11 Fan Fixing Hub 10014

12* Hot Gas Valve Coil 231294

13* Hot Gas Valve Body 20410

14 Suction Line for the spare parts code give us the s/n.

Common Parts

Ref. Spare Description Code

17 g. (Standard) D10047

32 g. D10090

14 g. D10418

41 g. D10480

Ref. 2 - Evaporator

Kind of Cube Code
