SL 140 NEW - 2014
HYDRAULIC CIRCUIT
vSL 140A / SL 140W
27
27
22
22
12
12
26
26
25
25
20
20
4 5 6
19
19
7
8
9
10
10
13
13
14
14
15
15
16
16
17
17
18
18
21
21
23
23
24
24
2 3
13
13
14
14
8
11
11
29
29
28
28
Ref. 20* - Ice Cubes Slide
17 g. (Standard) D12017
32 g. D12031
14 g. D12039
41 g. D12071
Kind of Cube Code
Ref. Spare Description Code
2 Sprayer D20002
3* Sprayers Bar Assembly Vedi Tabella
4* Overflow Cap 10305
5* Overflow Pipe 10133
6* OR Gasket for Overflow Pipe 20233
7 Overflow Pipe Nipple 10471
8 Silicone Gasket 13219
9 Gasket for Pump Suction/Delivery Pipes 13220
10 Insulated Pump Suction/Delivery Fitting C10653
11 Insulated Pump Suction Pipe C13175500
12 Insulated Pump Delivery Pipe C13175500
13 Semirigid Polyethylene Gasket 13007
14 Bin Discharge Nut 10096
15 Water Outlet Nipple 10472
16* Water Supply Pipe to the Evaporator C13125
18 Bulbe-holder Pipe 20521
19 Complete Basin Assembly C11176
20* Ice Cubes Slide Vedi Tabella
21* Flags Support Assy Till s/n. 817798 K10775
22 Special Screw Inox Till s/n. 817798 20009
23 Inner Basin 10034
24 Pump Suction Filter 20005
25 Sprayers Feeding Pipe 13005
26 Fittings Locking Ring 10654
27* Overflow Pipe 13109
28 Flags ABS Support Current Version 10760
29 Rod with Flags Current Version 10775
Common Parts
Ref. Spare Description Code
Parts for Air-Cooled Version Only
17 Discharges Manifold
C10006
Parts for Water-Cooled Version Only
17 Discharges Manifold
C26452
Ref. Spare Description Code
Ref. 3* - Sprayers Bar Assembly
17 g. (Standard) C20058
32 g. C20156
14 g. C20190
41 g. C20802
Kind of Cube Code
