The inlet and outlet tunnel sections have adjustable shutters.
The shutters are raised or lowered depending on the height of
the items to be cooled. This reduces the loss of cold.
The input unit (4) performs the function of a conventional
conveyor. It receives products for further cooling.
The belt tension unit (3) includes the drive mechanism of the
belt conveyor and the tension mechanism itself. The drive of a
belt is done by the motor reducer through a drum with a
rubber covering. The belt tension is made by two pneumatic
cylinders.
A scraper is installed at the exit of the belt to clean it.
Both the input and the tension unit have special protection
against belt distortion during the conveyor working. To do this,
they are equipped with special photo sensors that respond to
the shift of the belt. When the sensors are triggered, the belt
moving roller tilts, returning the belt to its original position (the
belt tension system is equipped with pneumatic cylinders).
———
Холодильный туннель представляет собой проточную холодильную
камеру, внутри которой движется транспортерная лента. Туннель имеет
различные модификации, различающиеся шириной ленты
транспортера и длиной.
10
