Kadzama 6 м [8/29] Constructive elements description
![Kadzama 6 м [8/29] Constructive elements description](/views2/1898082/page8/bg8.png)
Работа при снятых обшивках станины и с открытой дверцей шкафа
управления;
Любая переделка схемы управления, а также несанкционированное
изменение программного кода и несанкционированный доступ к
программе управления.
4.6. Не допустимо попадание посторонних предметов в холодильную
камеру.
4.7. Не допускается оставлять работающий туннель без присмотра.
5 — Constructive elements description
Описание конструктивных элементов
Cooling tunnel is a flow-through refrigerating chamber with a
moving conveyor belt inside. The tunnel has various
modifications differing in the width of the conveyor belt and
length.
Regardless of the modification, the tunnel consists of the
following units:
1 — Tunnel section
2 — Control panel
3 — Belt tension unit
4 — Input unit
5 — Cooling block
8
