Related Manuals
311075ZAD 3
Related Manuals
The following manuals are for Reactor E-10 components and accessories. Some are supplied with your package,
depending on its configuration. Manuals are also available at www.graco.com.
Systems
Manual in
English Description
311076 Displacement Pump Instruction-Parts
Manual
311210 Fluid Heater Instruction-Parts Manual
309550
Fusion
®
Air Purge Spray Gun
Instruction-Parts Manual
309856 Fusion Mechanical Purge Spray Gun
Instruction-Parts Manual
3A7314 Fusion Pro Connect Spray Gun Instruction
Manual
312666 Fusion CS Spray Gun Instruction-Parts
Manual
312185 MD2 Dispense Valve Instruction-Parts
Manual
3A2910 MD2 Cold Spray and Joint Fill Kits
332198 2K Manual Dispense Valve
Instruction-Parts Manual
Manual in
English Description
Part
Maximum
Working
Pressure,
psi
(MPa, bar)
Proportioner
(see page 4)
Unheated Hose
35 ft (10.6 m)
Gun
Model Part
AP9570 2000
(14, 140)
249570 249499 Fusion Air Purge 249810
AP9571 2000
(14, 140)
249571 249499 Fusion Air Purge 249810
AP9572 2000
(14, 140)
249572 249499 Fusion Air Purge 249810
CS9570 2000
(14, 140)
249570 249499 Fusion CS CS22WD
CS9571 2000
(14, 140)
249571 249499 Fusion CS CS22WD
CS9572 2000
(14, 140)
249572 249499 Fusion CS CS22WD
249806 2000
(14, 140)
249576 249633 MD2 Gun 255325
249808 2000
(14, 140)
249577 249633 MD2 Gun 255325
24R984 2000
(14, 140)
249576 24R823 2K Manual 24R021
24R985 2000
(14, 140)
249577 24R823 2K Manual 24R021
