Models
311075ZAD 5
Models
The model number, series letter, and serial number are located on the back of the Reactor E-10. For faster
assistance, please have that information ready before calling Customer Service.
* See page 17 for detailed electrical requirements.
Bare
Proportioner
Part, Series Volts
* Electrical
Connection Application
Maximum
Working
Pressure,
psi
(MPa, bar) Approvals
249570, A 120 V 15 A cord (motor)
15 A cord (heaters)
• Polyurethane Foam
• Hot Polyureas
2000
(14, 140)
249571, A 240 V 10 A cord (motor)
10 A cord (heaters)
• Polyurethane Foam
• Hot Polyureas
2000
(14, 140)
249572, A 240 V 20 A cord (motor and
heaters)
• Polyurethane Foam
• Hot Polyureas
2000
(14, 140)
249576, A 120 V 15 A cord (motor
only)
• Self-leveling Joint Fillers
• Cold Polyureas
2000
(14, 140)
249577, A 240 V 10 A cord (motor
only)
• Self-leveling Joint Fillers
• Cold Polyureas
2000
(14, 140)
9902471
Conforms to ANSI/UL
Std. 499 Certified to
CAN/CSA Std.
C22.2 Number88
Conforms to ANSI/UL
Std. 73 Certified to
CAN/CSA Std.
C22.2 Number 68
9902471
