MECHANICALLY LINKED PROPORTIONER
New Reactor Technology
Like you, we want customers to be completely satisfied with their spray foam and coatings application investment. Graco’s goal is to provide equipment advancements
that help you and your crews apply materials more accurately and more efficiently – as the material suppliers intended, to help grow your business.
Reactor Connect
Reactor Connect lets you view your fleet and make real time adjustments to your proportioner all from your smartphone.
Sprayers:
• Control your Reactor 2 with your phone
• Save time when you’re spraying. Adjust the Reactor without having to go back to your rig.
Owners/Managers:
• Monitor your rigs/crews with the multi-system dashboard
• Troubleshoot an issue quiuckly by being able to see
real-time machine conditions
• Provide documentation to a customer that material
was sprayed on-ratio to the manufacturers specs
• Use reports to better understand your
business, your equipment and
your employees
• Use the Account Management System
to setup a Company, invite users to join
your Company, and assign Reactors
to your Company for easy visibility
and access to automatic reporting
• Have your spray data
saved to the cloud
Ratio Assurance is now included with all new Reactor 2 elite models. Retrofit kits are available for
any Reactor 2 model in the field. For more information visit www.graco.com/ratioassurance
Ratio Assurance
Since no single method can easily and accurately detect all potential issues that may cause off-ratio
foam to be sprayed, Graco has designed a multi-tiered system with built in redundancies that will
provide the best results in monitoring and maintaining on-ratio spraying.
A robust Ratio Control System is more than just flow meters:
• Mechanically linked pumps
• Positive displacement piston pumps
• Inlet pressure monitoring
• Outlet pressure monitoring
• Flow meters
4
