Maintenance
309572ZAT 23
Maintenance
1. Before disconnecting or repairing hoses, relieve all
fluid pressure and shut off electrical power to
proportioner. See proportioner operation manual.
2. Be sure fluid is cool before disconnecting hoses.
Instructions for Replacing
Individual A or B Hose
Before disconnecting hoses, relieve all fluid pressure
and shut off electrical power to proportioner. See
proportioner operation manual.
Disconnect electrical wire from connectors (12).
Disconnect fluid hose and remove from bundle.
Install new hose in bundle, wrapping around other fluid
hose and air hose. Connect fluid hoses, see page 13.
Wrap all connections with electrical tape, see page 21.
