Graco Reactor 2 H-40 APH045 [29/34] Installation
![Graco Reactor 2 H-40 APH045 [29/34] Installation](/views2/1900952/page29/bg1d.png)
Parts
309572ZAT 29
15F144 Hose Wire Jumper
Use the 15F144 Hose Wire Jumper to heat only the
major volume hose, in a wide ratio system.
To build one complete 50 ft single side heated hose
bundle, order the following parts:
* Purchase locally.
† As required.
Installation:
1. Wrap hose wire jumper (100) around resin hose
(101) in a spiral fashion.
2. Connect resin hose wire (101a) to other side of
Power-Lock connector (100a); see page 13.
3. Wrap FTS cable (102) around resin hose (101) in a
spiral fashion.
4. Twist hoses (101 and 105) together to provide strain
relief.
5. Repeat steps 1-4 for each length of hose (101).
Connect hoses, electrical connectors, and cables;
see Connect Heated Hoses, page 13.
6. Install one -Lock connector (100a) between wires;
see page 13.
7. Connect FTS with a Non-Heated Whip Hose or
Remote Mix Manifold, page 19.
8. Install whip hose and gun. Ensure that gun is
grounded.
9. Connect hoses to proportioner.
10. Insulate and protect hoses. See Protective
Covering, page 21.
Ref. Part Description Qty.
100 15F144 JUMPER, hose wire 1
101 HOSE, resin, heated; 50 ft
(15.2 m) minimum; see tables
starting on page 4
1
102 24J523 CABLE, FTS 1
104 261670 FLUID TEMPERATURE
SENSOR; see page 24
1
105 * HOSE, hardener, unheated; 50
ft (15.2 m) minimum; customer
supplied
1
106 * CONNECTORS, fluid; as
required to complete assembly;
not shown
†
This hose must be used with an FTS and cable to
provide grounding.
