Technical Specifications
32 309572ZAT
Technical Specifications
Power-Lock Heated Hose
US Metric
Maximum Air Working Pressure 130 psi 0.9 MPa, 9 bar
Maximum Fluid Operating Temperature 180°F 82°C
Wetted Parts Nylon, Zinc-Plated Carbon Steel, 303 Stainless Steel, PTFE
Total Heating Load (2 Hoses)
1/4 in. diameter: 11 watts/foot 36 watts/meter
3/8 in. diameter: 13 watts/foot 43 watts/meter
1/2 in. diameter: 15 watts/foot 49 watts/meter
Whip Hose Maximum Fluid Working Pressure
246050*, 26C042, 25P770*, 25P771* 2000 psi 14 MPa, 138 bar
246055*, 26C043, 25P772*, 25P773* 3500 psi 24 MPa, 241 bar
246056 3500 psi 24 MPa, 241 bar
249586 2000 psi 14 MPa, 138 bar
258701 5000 psi 35 MPa, 345 bar
Standard 2 Component Hose Maximum Fluid Working Pressure
246045 2000 psi 14 MPa, 138 bar
246046 2000 psi 14 MPa, 138 bar
246047 2000 psi 14 MPa, 138 bar
246048 2000 psi 14 MPa, 138 bar
246049 2000 psi 14 MPa, 138 bar
246052 3500 psi 24 MPa, 241 bar
246053 3500 psi 24 MPa, 241 bar
246054 3500 psi 24 MPa, 241 bar
246074 2000 psi 14 MPa, 138 bar
246075 2000 psi 14 MPa, 138 bar
246076 2000 psi 14 MPa, 138 bar
246678 2000 psi 14 MPa, 138 bar
246679 3500 psi 24 MPa, 241 bar
249587 2000 psi 14 MPa, 138 bar
249588 3500 psi 24 MPa, 241 bar
256548 3500 psi 24 MPa, 241 bar
256549 2000 psi 14 MPa, 138 bar
261328 2000 psi 14 MPa, 138 bar
261332 5000 psi 35 MPa, 345 bar
261335 3500 psi 24 MPa, 241 bar
262203 5000 psi 35 MPa, 345 bar
24Y549* 2000 psi 14 MPa, 138 bar
24Y678* 2000 psi 14 MPa, 138 bar
24Y679* 3500 psi 24 MPa, 241 bar
26C193 3500 psi 24 MPa, 241 bar
