16. Troubleshooting
16. Troubleshooting
16.1 Error Code Displays
Error code display Description Countermeasures
CAL E2
The zero point shift is large during cali-
bration.
Remove items from the pan.
In order to postpone calibration,
press [POWER] key.
CAL E3 Large span error in PCAL Use the correct calibration weight.
CAL E4 Large span error in span calibration Use the correct calibration weight.
CHE X (X is a numeral)
(when the display stops here)
Internal malfunction Please contact a service represen-
tative.
Err 0X (X is a numeral)
Internal malfunction Please contact a service represen-
tative.
Err 20
An improper value setting was attempted. Enter the correct numbers or deci-
mal points.
Err 24 Power voltage error Check the power voltage.
