39
10. Calibration
10.1.2 Types of Calibration
Terms used in this manual:
Span calibration ...... Adjustment of the balance sensitivity using two weight values, zero
and near-capacity
Calibration test ...... Comparing the current calibration mass reading to the calibration
mass reading after the last span calibration.
Calibration ...... Specifies both span calibration and calibration test.
The AUW-D/AUW/AUX series have a built-in, motor-driven calibration weight. This weight allows easy
key calibration operations (i-CAL, i-tESt) without having to maintain external weights and manually load
and unload weights. These models are also equipped with functions for performing fully-automatic
span calibration whenever necessary. The two functions are PSC, for executing automatic span cali-
bration made necessary by temperature changes, and Clock-CAL, for performing automatic span cali-
bration at set times. Calibration can also be done with external calibration weights (E-CAL, E-tESt).
Calibration of the built-in calibration weight with external calibration weights (PCAL) is also possible.
Calibration of the AUY series must be done with external calibration weights as this series does not
have a built-in calibration weight.
Each calibration type is available for the listed series only.
*1 Default setting is ON for AUW-D / AUW / AUX
*2 Default preset calibration method for AUW-D/AUW/AUX
*3 Default preset calibration method for AUY
Calibration
Span calibration
(Balance is adjusted)
Calibration test
(Check only)
Fully-automatic Built-in External Built-in External
PSC
*1
(10.3.2)
Clock-CAL
(10.3.3)
i-CAL
*2
(10.2.1)
E-CAL
*3
(10.2.2)
i-tESt
(10.2.3)
E-tESt
(10.2.4)
AUW-D
AUW
AUX
AUW-D
AUW
AUW-D
AUW
AUX
AUW-D
AUW
AUX
AUY
AUW-D
AUW
AUX
AUW-D
AUW
AUX
AUY
