- 10 -
USB Chipset:
- 1 x USB Type-C
®
port on the back panel, with USB 3.2 Gen 2x2 support
- 1 x USB Type-C
®
port with USB 3.2 Gen 2 support, available through the
internal USB header
- 3 x USB 3.2 Gen 2 Type-A ports (red) on the back panel
- 4 x USB 3.2 Gen 1 ports (2 ports on the back panel, 2 ports available through
the internal USB header)
- 2 x USB 2.0/1.1 ports on the back panel
Chipset+USB 2.0 Hub:
- 4 x USB 2.0/1.1 ports available through the USB headers on the front of
GC-Z690I BTB PLUG
Internal
Connectors
1 x 24-pin ATX main power connector
1 x 8-pin ATX 12V power connector
1 x external power connector
(Note 1)
1 x CPU fan header
1 x water cooling CPU fan header
2 x system fan headers(SYS_FAN1/SYS_FAN2
(Note 1)
)
1 x addressable LED strip header
(Note 1)
1 x RGB LED strip header
2 x M.2 Socket 3 connectors(M2A_CPU
(Note 2)
/M2P_SB
(Note 1)
)
2 x SATA 6Gb/s connectorsj
4 x SATA 6Gb/s connectorsk
1 x front panel header
1 x front panel audio header(routed from the adapter card on the rear panel)
1 x speaker header
1 x USB Type-C
®
header, with USB 3.2 Gen 2 support
1 x USB 3.2 Gen 1 header
1 x USB 2.0/1.1 header
(Note 1)
1 x reset button
(Note 1)
1 x reset jumper
1 x Clear CMOS jumper
Back Panel
Connectors
2 x SMA antenna connectors (2T2R)
1 x DisplayPort
1 x HDMI port
1 x USB Type-C
®
port, with USB 3.2 Gen 2x2 support
3 x USB 3.2 Gen 2 Type-A ports (red)
2 x USB 3.2 Gen 1 ports
2 x USB 2.0/1.1 ports
1 x Q-Flash Plus button
1 x RJ-45 port
2 x audio jacks
j Only for Z690I AORUS ULTRA.
k Only for Z690I A ULTRA DDR4.
(Note 1) The connector is on the front of GC-Z690I BTB PLUG.
(Note 2) The connector is on the back of GC-Z690I BTB PLUG.
