- 6 -

1-2 Motherboard Block Diagram

LGA1700 CPU

CPU CLK+/- (80~800 MHz)

DDR5 4800/4000 MT/sj

DDR4 3200/3000/2933/2666/2400/2133 MT/sk

DMI 4.0

PCI Express 5.0

Bus

1 PCI Express x16

x16

DDI

DisplayPort

DDI

HDMI

LAN

RJ45

SPI

Bus

PCI Express 3.0 Bus

4 USB 2.0/1.1

USB 2.0

Hub

Intel

Z690

BIOS

4 SATA 6Gb/sk

iTE

Super I/O

1 USB Type-C

with USB 3.2 Gen 2 support

3 USB 3.2 Gen 2 Type-A

4 USB 3.2 Gen 1

Line Out

MIC

CODEC

Intel

2.5GbE LAN

1 USB Type-C

with USB 3.2 Gen 2x2 support

1 M.2 Socket 3

(M2P_SB)

M.2 WIFI

eSPI

Bus

2 USB 2.0/1.1

PCI Express 4.0 Bus

1 M.2 Socket 3

(M2A_CPU)

2 SATA 6Gb/sj

j Only for Z690I AORUS ULTRA.

k Only for Z690I A ULTRA DDR4.
