- 10 -

Please visit GIGABYTE's website for support lists of CPU, memory modules,

SSDs, and M.2 devices.

Please visit the Support\Utility page on GIGABYTE's website to download the latest version

of apps.

B660M AORUS

ELITE AX DDR4

B660M AORUS

ELITE DDR4

Bundled

Software

 Norton

Internet Security (OEM version)

 LAN bandwidth management software

Operating

System

 Support for Windows 11 64-bit

 Support for Windows 10 64-bit

Form Factor

 Micro ATX Form Factor; 24.4cm x 24.4cm

* GIGABYTE reserves the right to make any changes to the product specications and product-related information without

prior notice.
