- 18 -
2-7 Internal Connectors
Read the following guidelines before connecting external devices:
• First make sure your devices are compliant with the connectors you wish to connect.
• Before installing the devices, be sure to turn off the devices and your computer. Unplug the power
cord from the power outlet to prevent damage to the devices.
• After installing the device and before turning on the computer, make sure the device cable has
been securely attached to the connector on the motherboard.
1) ATX_12V_2X2/ATX_12V_2X4
2) ATX
3) CPU_FAN
4) SYS_FAN1/2/3
5) LED_C1/LED_C2
6) D_LED1/D_LED2
7) SATA3 4/5/6/7
8) M2A_CPU/M2P_SB
9) F_PANEL
10) F_AUDIO
11) F_U32C
12) F_U32_1/F_U32_2
13) F_USB1
14) SPI_TPM
15) COM
16) THB_C1/THB_C2
17) BAT
18) CLR_CMOS
19) RST_SW/RST
20) QFLASH_PLUS
9
12
11
2
6
16
7
13
410 14
51
65 18
3
8
8
4
4
15
17
1920
