Installation Notices for the M.2 and SATA Connectors:
The availability of the SATA connectors may be affected by the type of device installed in the M.2
sockets. The M2P_SB connector shares bandwidth with the SATA3 1 connector. Refer to the following
table for details.
• M2P_SB:
SATA3 0 SATA3 1 SATA3 2 SATA3 3 SATA3 4 SATA3 5
M.2 SATA SSD
a
r
a a a a
M.2 PCIe SSD
a a a a a a
No M.2 SSD Installed
a a a a a a
a: Available, r: Not available
Connector
Type of
M.2 SSD
• M2A_CPU
(Note)
/M2B_SB:
SATA3 0 SATA3 1 SATA3 2 SATA3 3 SATA3 4 SATA3 5
M.2 PCIe SSD *
a a a a a a
No M.2 SSD Installed
a a a a a a
a: Available, r: Not available
* The M2A_CPU
(Note)
/M2B_SB connector supports only PCIe SSDs.
Connector
Type of
M.2 SSD
(Note) Supported by 11th Generation processors only.
- 20 -
