- 3 -
Table of Contents
Z590 AORUS ULTRA Motherboard Layout .....................................................................4
Z590 AORUS ULTRA Motherboard Block Diagram ......................................................... 5
Chapter 1 Hardware Installation .....................................................................................6
1-1 Installation Precautions .................................................................................... 6
1-2 Product Specications ...................................................................................... 7
1-3 Installing the CPU .......................................................................................... 11
1-4 Installing the Memory ..................................................................................... 11
1-5 Installing an Expansion Card ......................................................................... 12
1-6 Setting up an AMD CrossFire
™
Conguration ................................................ 12
1-7 Back Panel Connectors .................................................................................. 13
1-8 Onboard Buttons and LEDs ........................................................................... 15
1-9 Internal Connectors ........................................................................................ 16
Chapter 2 BIOS Setup ..................................................................................................27
2-1 Startup Screen ............................................................................................... 27
2-2 The Main Menu .............................................................................................. 28
2-3 Smart Fan 6 .................................................................................................. 29
2-4 Favorites (F11) ............................................................................................... 31
2-5 Tweaker .......................................................................................................... 32
2-6 Settings .......................................................................................................... 37
2-7 System Info. ................................................................................................... 42
2-8 Boot ................................................................................................................ 43
2-9 Save & Exit ..................................................................................................... 46
Chapter 3 Appendix ......................................................................................................47
3-1 Conguring a RAID Set .................................................................................. 47
3-2 Installing Intel
®
Optane
™
Memory and Storage Management ........................ 48
3-3 Drivers Installation .......................................................................................... 50
3-4 Debug LED Codes ......................................................................................... 51
Regulatory Notices .................................................................................................... 55
Contact Us ................................................................................................................ 60
