- 11 -
Hardware Installation
LAN 1 x Aquantia 10GbE LAN chip (10 Gbit/5 Gbit/2.5 Gbit/1 Gbit/100 Mbit) (LAN1)
1 x Intel
®
2.5GbE LAN chip (2.5 Gbit/1 Gbit/100 Mbit) (LAN2)
Wireless
Communication
Module
Intel
®
Wi-Fi 6E AX210
- WIFIa,b,g,n,ac,ax,supporting2.4/5/6GHzcarrierfrequencybands
- BLUETOOTH 5.2
- Supportfor11ax160MHzwirelessstandardandupto2.4Gbpsdatarate
* Actual data rate may vary depending on environment and equipment.
Expansion Slots 1 x PCI Express x16 slot, running at x16 (PCIEX16)
* For optimum performance, if only one PCI Express graphics card is to be installed,
be sure to install it in the PCIEX16 slot.
1 x PCI Express x16 slot, running at x8 (PCIEX8)
* The PCIEX8 slot shares bandwidth with the PCIEX16 slot. When the PCIEX8 slot is
populated, the PCIEX16 slot operates at up to x8 mode.
(The PCIEX16 and PCIEX8 slots conform to PCI Express 4.0 standard.)
(Note)
1 x PCI Express x16 slot, running at x4 (PCIEX4)
(The PCI Express x4 slot conforms to PCI Express 3.0 standard.)
Multi-Graphics
Technology
Support for AMD Quad-GPU CrossFire
™
and 2-Way AMD CrossFire
™
technologies
Storage Interface CPU:
- 1xM.2connector(Socket3,Mkey,type2242/2280/22110PCIe4.0x4/x2
SSD support) (M2P_CPU)
(Note)
Chipset:
- 1xM.2connector(Socket3,Mkey,type2242/2280/22110SATAandPCIe
3.0x4/x2SSDsupport)(M2A_SB)
- 1xM.2connector(Socket3,Mkey,type2242/2260/2280/22110SATAand
PCIe3.0x4/x2SSDsupport)(M2M_SB)
- 6xSATA6Gb/sconnectors
* Refer to "1-9 Internal Connectors," for the installation notices for the M.2 and SATA
connectors.
Support for RAID 0, RAID 1, RAID 5, and RAID 10
Intel
®
Optane
™
Memory Ready
USB Chipset+Intel
®
Thunderbolt
™
4 Controller:
- 2 x USB Type-C
®
ports on the back panel, with USB 3.2 Gen 2 support
Chipset:
- 1 x USB Type-C
®
port with USB 3.2 Gen 2x2 support, available through the
internal USB header
- 2 x USB 3.2 Gen 2 Type-A ports (red) on the back panel
Chipset+2 USB 3.2 Gen 2 Hubs:
- 6 x USB 3.2 Gen 2 Type-A ports (red) on the back panel
- 2 x USB 3.2 Gen 1 ports available through the internal USB header
Chipset+USB 2.0 Hub:
- 4xUSB2.0/1.1portsavailablethroughtheinternalUSBheaders(withthe
included front USB header extension cable)
(Note) Supported by 11th Generation processors only.
