- 10 -
Hardware Installation
1-2 ProductSpecications
CPU LGA1200 package:
- 11th Generation Intel
®
Core
™
i9processors/Intel
®
Core
™
i7processors/
Intel
®
Core
™
i5 processors
- 10th Generation Intel
®
Core
™
i9processors/Intel
®
Core
™
i7processors/
Intel
®
Core
™
i5processors/Intel
®
Core
™
i3processors/
Intel
®
Pentium
®
processors/Intel
®
Celeron
®
processors*
* Limited to processors with 4 MB Intel
®
Smart Cache, Intel
®
Celeron
®
G5xx5 family.
(Go to GIGABYTE's website for the latest CPU support list.)
L3 cache varies with CPU
Chipset Intel
®
Z590 Express Chipset
Memory 11th Generation Intel
®
Core
™
i9/i7/i5 processors
- SupportforDDR43200/3000/2933/2666/2400/2133MHzmemory
modules
10th Generation Intel
®
Core
™
i9/i7 processors
- SupportforDDR42933/2666/2400/2133MHzmemorymodules
10th Generation Intel
®
Core
™
i5/i3/Pentium
®
/Celeron
®
processors:
- SupportforDDR42666/2400/2133MHzmemorymodules
4 x DDR4 DIMM sockets supporting up to 128 GB (32 GB single DIMM capacity)
of system memory
Dual channel memory architecture
Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in
non-ECC mode)
Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules
Support for Extreme Memory Prole (XMP) memory modules
(Go to GIGABYTE's website for the latest supported memory speeds and memory
modules.)
Onboard
Graphics
Integrated Graphics Processor+Intel
®
Thunderbolt
™
4 Controller:
- 2 x Intel
®
Thunderbolt
™
4 connectors (USB Type-C
®
ports), supporting
DisplayPort and Thunderbolt
™
video outputs and a maximum resolution of
5120x2880@60Hzwith24bpp(viasingledisplayoutput)
* Because of the limited I/O resources of the PC architecture, the number of
Thunderbolt
™
devices that can be used is dependent on the number of the PCI
Express devices being installed. (Refer to Chapter 1-7, "Back Panel Connectors,"
for more information.)
* Support for DisplayPort 1.4 version and HDCP 2.3
Integrated Graphics Processor-Intel
®
HD Graphics support:
- 1xHDMIport,supportingamaximumresolutionof4096x2160@30Hz
* Support for HDMI 1.4 version and HDCP 2.3.
(Graphics specications may vary depending on CPU support.)
Audio Realtek
®
ALC1220-VB codec+ESS ES9018K2M DAC+TI OPA1622 operational
amplier
* The front panel line out jack supports DSD audio.
Support for DTS:X
®
Ultra
High Denition Audio
2/4/5.1/7.1-channel
Support for S/PDIF Out
