Makita M3602 [2/3] Model no m3602 router

Model No.M3602 ROUTER

Item Parts No. Description I/C Qty New/Old Opt. 1 Opt. 2 Note

001 266326-2 TAPPING SCREW 4X18 2

002 413B12-0 TOP COVER 1

003 141F96-9 MOTOR HOUSING COMPLETE 1

󳢢󳢢󳢢󳢢C10 643564-7 BRUSH HOLDER 2

󳢢󳢢󳢢󳢢C20 816811-1 SCALE LABEL 1

004 620H00-8 CONTROLLER 1

005 594784-5 FIELD ASS'Y 240V 1

󳢢󳢢󳢢󳢢C10 654451-5 RING TERMINAL 2

󳢢󳢢󳢢󳢢C20 654486-6 PARALLEL SPLICE 2

006 418486-8 BAFFLE PLATE 1

007 211381-9 BALL BEARING 629ZZ 1

008 681666-1 INSULATION WASHER 1

009 517884-4 ARMATURE ASS'Y 240V 1

󳢢󳢢󳢢󳢢D10 INC. 7,8,10

010 240069-4 FAN 83 1

011 285711-0 BEARING RETAINER 50 1

012 211335-6 BALL BEARING 6004ZZ 1

013 187512-1 GRIP L SET 1

015 141868-6 MOTOR BRACKET COMPLETE 1

016 911268-2 PAN HEAD SCREW M5X45 4

017 233397-4 COMPRESSION SPRING 11 1

018 324424-9 HALF NUT 1

019 763629-0 COLLET NUT 1

020 763628-2 COLLET CONE 12MM 1

021 911353-1 PAN HEAD SCREW M6X30 2

022 187515-5 GRIP R SET 1

023 266326-2 TAPPING SCREW 4X18 4

024 265099-4 PAN HEAD SCREW M4X14 1

025 454033-1 LOCK LEVER 1

026 266335-1 SET BOLT M8X16 1

027 231670-6 TORSION SPRING 16 1

028 286270-7 CAP 11 1

029 256482-6 SHOULDER PIN 6 1

030 233396-6 COMPRESSION SPRING 7 1

031 265759-8 THUMB SCREW M10X80 1

032 265135-6

+ COUNTERSUNK HEAD

SCREW M4X10

033 266328-8 TAPPING SCREW 5X80 2

034 643700-5 BRUSH HOLDER CAP 7-18 2

035 191953-5 CARBON BRUSH CB-203 1

036 682574-9 CORD GUARD 10-90 1

037 665852-2

POWER SUPPLY CORD 1.0-2-

2.0

Please order the parts with part number. Print Date 23/5/2022
