- 4 -
1-1 Motherboard Layout
Chapter 1 Product Introduction
Temperature sensor
KB_MS_USB
CPU_FAN
SYS_FAN1
ATX
A520M K
A520M K V2
AUDIO
DDR4_A1
DDR4_B1
BAT
ATX_12V
AMD
A520
HDMI
VGA j
CODEC
M_BIOS
PCIEX16
PCIEX1
iTE
®
Super I/O
Realtek
®
GbE LAN
F_U32TPM
SPEAKER
F_USB1
F_PANEL
F_USB2
F_AUDIO
0 1 2 3
U32_LAN
Socket AM4
U32
CLR_CMOS
CI
M2A_CPU
80
SATA3 SATA3
j Only for A520M K V2.
