Asus PRIME Z790M-PLUS D4 [42/66] Chapter 2

2-10

Chapter 2: Basic Installation

Chapter 2

3. Place eight (8) screws into the holes indicated by circles to secure the motherboard to

the chassis.

DO NOT over tighten the screws! Doing so can damage the motherboard.
